DLN-184 < DISASSEMBLY AND ASSEMBLY > [TRANSFER: ATX14B] TRANSFER ASSEMBLY 27. Install the new oil seal in the front case using Tool. CAUTION: • Do not reuse oil seal. 28. Install the shift lever to the shift cross. DLN-149, "Disassembly and Assembly" . Rear Case 1. Apply petroleum jelly to the circumference of the new rear oil CAUTION: • Do not reuse oil seal. 2. Apply petroleum jelly to the circumference of the new dust cover. CAUTION: • Do not reuse dust cover. 3. Install the new dust cover using Tool. 4. Install the air breather into the rear case. 5. Remove all the sealant from the rear case to center case mating CAUTION: Remove all foreign materials such as water, oil, and grease 6. Apply liquid gasket to the entire rear case mating surface of the CAUTION: Do not to allow Liquid Gasket to enter stem bleeder hole. Tool number : ST22360002 (J-25679-01) SDIA2182E Tool number : ST30720000 (J-25405) SDIA2204E SDIA3436E Tool number : KV40105310 ( — ) SDIA2205E |
