AV-248

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

AV CONTROL UNIT

DTC Index

INFOID:0000000001450754

Self-diagnosis results display item

ALNIA0605GB

AV

AV CONTROL UNIT

AV-249

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

Error item

Refer to

CAN COMM CIRCUIT [U1000]

AV-166, "DTC Logic"

CONTROL UNIT (CAN) [U1010]

AV-167, "DTC Logic"

Control Unit FLASH-ROM [U1200]

AV-168, "DTC Logic"

CAN CONT [U1216]

AV-169, "DTC Logic"

SWITCHE CONN [U1240]

AV-170, "Description"

FRONT DISP CONN [U1243]

AV-171, "DTC Logic"

DVD DECK [U1248]

AV-173, "DTC Logic"

SAT CONN [U1255]

AV-174, "DTC Logic"

HAND FREE CONN [U1256]

AV-175, "Description"

AV COMM CIRCUIT [U1300]

AV-176, "Description"

CONTROL UNIT (AV) [U1310]

AV-177, "DTC Logic"

AV-250

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

DISPLAY UNIT

DISPLAY UNIT

Reference Value

INFOID:0000000001468873

TERMINAL LAYOUT

PHYSICAL VALUES

AWNIA0149ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(B)

Ground

Ground

—

Ignition

switch

ON

—

0V

2

(O)

Ground

Inverter VCC

Input

Ignition

switch

ACC

—

9V

3

(R)

Ground

Signal VCC

Input

Ignition

switch

ACC

—

9V

4

(R)

Ground

AUX image ground

—

Ignition

switch

ON

—

0V

5

—

Shield

—

—

—

—

6

(B)

Ground

RGB signal (G: green)

Input

Ignition

switch

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by
selecting“Color Spectrum
Bar” on DISPLAY DIAGNO-
SIS screen.

7

—

Shield

—

—

—

—

8

(B)

Ground

Horizontal synchronizing
(HP) signal

Output

Ignition

switch

ON

—

SKIB2236J

SKIB3601E

AV

DISPLAY UNIT

AV-251

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

9

(G)

Ground

RGB area (YS) signal

Input

Ignition

switch

ON

At RGB image displayed

5V

At rear view camera image
displayed

11

(V)

Ground

Communication signal
(CONT

→

DISP)

Input

Ignition

switch

ON

When adjusting display-
brightness

13

(SB)

Ground

Inverter ground

—

Ignition

switch

ON

—

0V

14

(BR)

Ground

Signal ground

—

Ignition

switch

ON

—

0V

15

(G)

—

AUX image synchronizing
signal

Input

—

—

—

17

(W)

Ground

RGB signal (R: red)

Input

Ignition

switch

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.

18

(R)

Ground

RGB signal (B: blue)

Input

Ignition

switch

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by
selecting“Color Spectrum
Bar” on DISPLAY DIAGNO-
SIS screen.

19

(R)

Ground

RGB synchronizing signal

Input

Ignition

switch

ON

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

PKIB4948J

PKIB5039J

SKIB2238J

SKIB2237J

SKIB3603E

AV-252

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

DISPLAY UNIT

20

(W)

Ground

Vertical synchronizing (VP)
signal

Output

Ignition

switch

On

—

21

—

Shield

—

—

—

—

22

(LG)

Ground

Communication signal
(DISP

→

CONT)

Output

Ignition

switch

ON

When adjusting display-
brightness

23

—

Shield

—

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3598E

PKIB5039J

AV

BOSE SPEAKER AMP

AV-253

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

BOSE SPEAKER AMP

Reference Value

INFOID:0000000001450756

TERMINAL LAYOUT

PHYSICAL VALUES

AWNIA0147ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(Y)

Ground

Battery power

Input

—

—

12V

9

(G)

10

(B)

Audio signal rear door
speaker and tweeter LH

Output

Ignition

switch

ON

Audio output

11

(GR)

12

(O)

Audio signal rear door
speaker and tweeter RH

Output

Ignition

switch

ON

Audio output

13

(LG)

14

(L)

Audio signal front door
speaker and tweeter LH

Output

Ignition

switch

ON

Audio output

15

(W)

16

(R)

Audio signal front door
speaker and tweeter RH

Output

Ignition

switch

ON

Audio output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AV-254

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

BOSE SPEAKER AMP

17

(B)

Ground

Ground

—

Ignition

switch

ON

—

0V

19

(SB)

3

(B)

Audio signal subwoofer

Output

Ignition

switch

ON

Audio output

22

(Y)

Ground

Subwoofer amp. ON signal

Output

Ignition

switch

ACC

Audio output

12V

24

(R)

23

(B)

Audio signal rear RH

Input

Ignition

switch

ON

Audio input

26

(L)

25

(Y)

Audio signal rear LH

Input

Ignition

switch

ON

Audio input

28

(G)

27

(W)

Audio signal front RH

Input

Ignition

switch

ON

Audio input

30

(R)

29

(B)

Audio signal front LH

Input

Ignition

switch

ON

Audio input

31

(SB)

Ground

Amp. ON signal

Input

Ignition

switch

ON

Audio output

12V

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AV

SATELLITE RADIO TUNER

AV-255

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

SATELLITE RADIO TUNER

Reference Value

INFOID:0000000001468874

PHYSICAL VALUES

AWNIA0150ZZ

Terminal

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

22

(R)

21

(G)

Satellite radio sound signal
LH

Output

Ignition

switch

ON

When satellite radio mode
is selected

24

(B)

23

(W)

Satellite radio sound signal
RH

Output

Ignition

switch

ON

When satellite radio mode
is selected

25

—

Shield

—

—

—

—

26

—

Shield

—

—

—

—

28

(O)

Ground

Request signal
(SAT

→

CONT)

Output

Ignition

switch

ON

When satellite radio mode
is selected

29

(P)

Ground

Communication signal
(SAT

→

CONT)

Output

Ignition

switch

ON

When satellite radio mode
is selected

SKIB3609E

SKIB3609E

SKIA9299J

SKIA9300J
