AUTOMATIC DRIVE POSITIONER SE-37 C D E F G H J K L M A B SE 2006 Pathfinder SELF-DIAGNOSIS RESULTS DISPLAY ITEM LIST NOTE: ● If park position switch error is detected, manual adjustable pedal operation cannot be performed when ● The displays of CAN communication and park position switch display error detecting condition from mem- – If error is detected in the past and present error is detected, “CRNT” is displayed. – If error is detected in the past and present error is not detected, “PAST” is displayed. – If error has never been detected, nothing is displayed on “TIME”. ● Any items other than CAN communication and park position switch count error detection frequency – If error was detected in the past, error detection frequency from memory erase to the present is displayed – If error has never been detected, nothing is displayed on “TIME”. – Can clear the detected memory. DATA MONITOR CAN DIAGNOSIS SUPPORT MONITOR CONSULT-II display Item Malfunction is detected when... Reference page CAN COMM CIRC CAN communication Malfunction is detected in CAN communication.
SEAT SLIDE Seat slide motor When any manual and automatic operations are not performed, if SEAT RECLINING Seat reclining motor When any manual and automatic operations are not performed, if SEAT LIFTER FR Seat lifting FOR- When any manual and automatic operations are not performed, if SEAT LIFTER RR Seat lifting BACK- When any manual and automatic operations are not performed, if ADJ PEDAL Pedal adjust motor When any manual and automatic operations are not performed, if ADJ PEDAL SEN- Pedal adjust sensor When pedal adjust sensor detects 0.5V or lower, or 4.5V or higher, DETENT SW Park SW With the A/T selector lever in P position (park position switch OFF), if UART COMM UART communica- Malfunction is detected in UART communication. Monitor item [UNIT] Contents INITIAL DIAG [OK/NG] When CAN communication circuit is malfunctioning, it displays “NG”. TRANSMIT DIAG [OK/UNKWN] Displays [OK/UNKWN] condition of the CAN communication judged by each sig- BCM [OK/UNKWN] METER/M&A [OK/UNKWN] ECM [OK/UNKWN] |
