DTC P2122, P2123 APP SENSOR EC-587 C D E F G H I J K L M A EC 2006 Pathfinder 6. REPLACE ACCELERATOR PEDAL ASSEMBLY 1. Replace accelerator pedal assembly. 2. Perform EC-77, "Accelerator Pedal Released Position Learning" 3. Perform EC-77, "Throttle Valve Closed Position Learning" . 4. Perform EC-77, "Idle Air Volume Learning" . >> INSPECTION END 7. CHECK INTERMITTENT INCIDENT Refer to EC-144, "TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT" >> INSPECTION END Component Inspection UBS00KH5 ACCELERATOR PEDAL POSITION SENSOR 1. Reconnect all harness connectors disconnected. 2. Turn ignition switch ON. 3. Check voltage between ECM terminals 106 (APP sensor 1 sig- 4. If NG, replace accelerator pedal assembly and go to next step. 5. Perform EC-77, "Accelerator Pedal Released Position Learning" 6. Perform EC-77, "Throttle Valve Closed Position Learning" . 7. Perform EC-77, "Idle Air Volume Learning" . Removal and Installation UBS00KH6 ACCELERATOR PEDAL Refer to ACC-3, "ACCELERATOR CONTROL SYSTEM" Terminal Accelerator pedal Voltage 106 Fully released 0.65 - 0.87V Fully depressed More than 4.3V 98 Fully released 0.28 - 0.48V Fully depressed More than 2.0V MBIB0023E |
