SERVICE DATA AND SPECIFICATIONS (SDS)
RSU-23
< SERVICE DATA AND SPECIFICATIONS (SDS)
C
D
F
G
H
I
J
K
L
M
A
B
RSU
N
O
P
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Wheel Alignment (Unladen*)
INFOID:0000000009177409
*: Fuel, engine coolant, and lubricants are full. Spare tire, jack, hand tools, and mats are in designated positions.
Ball Joint
INFOID:0000000009177410
Wheelarch Height
INFOID:0000000009177411
UNITED STATES
Item
Standard
Camber
Degree minute (Decimal degree)
Minimum
–1
° 05′ (–1.08°)
Nominal
–0
° 35′ (–0.58°)
Maximum
–0
° 05′ (–0.08°)
Total toe-in
Distance (A - B)
Minimum
Out 0.8 mm (Out 0.031 in)
Nominal
In 2.2 mm (In 0.087 in)
Maximum
In 5.2 mm (In 0.205 in)
Angle (LH and RH)
Degree minute
(Decimal degree)
Minimum
Out 0
° 2′ 24″ (Out 0.04°)
Nominal
In 0
° 9′ 36″ (In 0.16°)
Maximum
In 0
° 21′ 36″ (In 0.36°)
SFA234AC
Item
Standard
Swing torque
0.5 – 3.4 N·m (0.05 – 0.35 kg-m, 4 – 30 in-lb)
Measurement on spring balance (cotter pinhole position)
8.1 – 54.8 N (0.83 – 5.59 kg, 1.82 – 12.32 lb)
Axial end play
0 mm (0 in)
