< ECU DIAGNOSIS INFORMATION >
[LH FRONT ONLY AUTO DOWN]
POWER WINDOW MAIN SWITCH
9
(SB)
Ground
Rear power window motor LH
UP signal
Output
When rear LH switch in
power window main switch
is operated UP.
Battery voltage
10
(BR)
Ground RAP signal
Input
IGN SW ON
Battery voltage
Within 45 second after ig-
nition switch is turned to
OFF.
Battery voltage
When driver side or pas-
senger side door is opened
during retained power op-
eration.
0
12
(BR)
Ground Encoder ground
—
—
0
14
(LG)
Ground Encoder power supply
Output
When ignition switch ON or
power window timer oper-
ates.
10
16
(R)
2
Front power window motor
RH UP signal
Output
When front RH switch in
power window main switch
is operated UP.
Battery voltage
17
(Y)
19
Front power window motor LH
UP signal
Output
When front LH switch in
power window main switch
is operated UP.
Battery voltage
18
(Y)
Ground Battery power supply
Input
—
Battery voltage
19
(L)
17
Front power window motor LH
DOWN signal
Output
When front LH switch in
power window main switch
is operated DOWN.
Battery voltage
Terminal No.
(Wire color)
Description
Condition
Voltage
(Approx.)
+
-
Signal name
Input/
Output
