PCS-32 < REMOVAL AND INSTALLATION > [IPDM E/R] IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) REMOVAL AND INSTALLATION IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE Removal and Installation INFOID:0000000009175206 CAUTION: IPDM E/R integrated relays are not serviceable parts and must not be removed from the unit. REMOVAL 1. Disconnect the negative battery terminal. Refer to PG-90, "Removal and Installation" 2. Release the pawls (A) and separate the IPDM E/R (1) from the case. 3. Disconnect all harness connectors (1) and remove the IPDM E/ R (2). INSTALLATION Installation is in the reverse order of removal. ALMIA0560ZZ ALMIA0561ZZ |
