ENGINE MAINTENANCE (VQ35DE) MA-27 < PERIODIC MAINTENANCE > C D E F G H I J K L M B MA N O A 7. Install engine under cover. Refer to . ENGINE OIL : Changing Engine Oil INFOID:0000000009761158 WARNING: • Be careful not to burn yourself, as the engine oil may be hot. • Prolonged and repeated contact with used engine oil may cause skin cancer; try to avoid direct skin contact with used engine oil. If skin contact is made, wash thoroughly with soap or hand cleaner as soon as possible. 1. Position the vehicle so it is level on the hoist. CAUTION: • Be sure to clean the oil pan drain plug and install with a new washer. • The refill capacity depends on the engine oil temperature and drain time. Use the specifications for reference only. Always use the dipstick to determine when the proper amount of engine oil is in the engine. 7. Warm up the engine and check around the oil pan drain plug and oil filter for engine oil leaks. CAUTION: Do not overfill the engine with engine oil. OIL FILTER INFOID:0000000009761159 REMOVAL 1. Drain engine oil. Refer to MA-27, "ENGINE OIL : Changing Engine Oil" . 2. Remove front fender protector side cover (RH). Refer to EXT-28, "FENDER PROTECTOR : Exploded . 3. Remove the oil filter using Tool (A) as shown. WARNING: Be careful not to burn yourself, as the engine oil may be hot. CAUTION: • When removing, prepare a shop cloth to absorb any engine oil leaks or spills. • Do not allow engine oil to adhere to the drive belts. • Completely wipe off any engine oil that adheres to the engine and the vehicle. Engine oil specification and : Refer to (United States and Canada) or (Mexico). Oil pan drain plug : 34.3 N·m (3.5 kg-m, 25 ft-lb) Tool number : KV10115801 (J-38956) ALBIA0617GB |
