B2623 INSIDE ANTENNA

2.

CHECK INSIDE KEY ANTENNA CIRCUIT

1. Disconnect BCM connector and inside key antenna (luggage room) connector.

2. Check continuity between BCM harness connector and inside key antenna (luggage room) harness con-

nector.

3. Check continuity between BCM harness connector and ground.

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Repair or replace harness.

3.

CHECK INSIDE KEY ANTENNA INPUT SIGNAL 2

1. Replace inside key antenna (luggage room). (New antenna or other antenna)

2. Connect BCM connector and inside key antenna (luggage room) connector.

3. Check signal between BCM harness connector and ground using oscilloscope.

Is the inspection result normal?

YES

>> Replace inside key antenna (luggage room). Refer to

DLK-315, "LUGGAGE ROOM : Removal

and Installation"

.

NO

>> Replace BCM. Refer to

BCS-80, "Removal and Installation"

.

BCM

Inside key antenna (luggage room)

Continuity

Connector

Terminal

Connector

Terminal

M20

100

B76

1

Yes

99

2

BCM

Ground

Continuity

Connector

Terminal

M20

100

No

99

(+)

(–)

Condition

Signal

(Reference value)

BCM

Connector

Terminal

M20

100, 99

Ground

When Intelligent Key is in the an-
tenna detection area

When Intelligent Key is not in the
antenna detection area

JMKIA3839GB

JMKIA5951GB

B26FD SHIFT LOCK SOLENOID

DLK-155

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

B26FD SHIFT LOCK SOLENOID

DTC Logic

INFOID:0000000009175694

DTC DETECTION LOGIC

DTC CONFIRMATION PROCEDURE

1.

PERFORM DTC CONFIRMATION PROCEDURE

1. Turn ignition switch ON.

2. Check “Self Diagnostic Result” mode of “BCM” using CONSULT.
Is DTC detected?

YES

>> Refer to

DLK-155, "Diagnosis Procedure"

.

NO

>> Shift lock solenoid is OK.

Diagnosis Procedure

INFOID:0000000009175695

Regarding Wiring Diagram information, refer to

TM-74, "Wiring diagram"

.

1.

 CHECK POWER SOURCE (STOP LAMP SWITCH)

1. Turn ignition switch OFF.

2. Disconnect stop lamp switch connector.

3. Check voltage between stop lamp switch connector E38 terminal 1 and ground.

Is the inspection result normal?

YES

>> GO TO 2.

NO

>> Check the following:

• Harness for short or open between fuse block (J/B) and stop lamp switch

• 10A fuse (No. 10, located in fuse block [J/B])

2.

CHECK STOP LAMP SWITCH

Check stop lamp switch. Refer to

TM-179, "Component Inspection (Stop Lamp Switch)"

.

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Replace stop lamp switch. Refer to

BR-20, "Exploded View"

.

3.

CHECK GROUND CIRCUIT (STOP LAMP RELAY)

1. Remove the stop lamp relay.

2. Check continuity between stop lamp relay connector E39 terminal 2 and ground.

DTC

CONSULT display

description

DTC detecting condition

Possible cause

B26FD

SHIFT LOCK SOLE-
NOID

 BCM shift lock solenoid output control is OFF but
shift lock solenoid output feedback is ON.

• Shift lock solenoid
• Harness or connector
• Shift lock solenoid circuit is open or

shorted

Stop lamp switch

Ground

Voltage

Connector

Terminal

E38

1

Battery voltage

Stop lamp relay

Ground

Continuity

Connector

Terminal (+)

E39

2

Yes

DLK-156

< DTC/CIRCUIT DIAGNOSIS >

B26FD SHIFT LOCK SOLENOID

Is the inspection result normal?

YES

>> GO TO 4.

NO

>> Repair or replace damaged parts.

4.

CHECK HARNESS BETWEEN STOP LAMP RELAY AND BCM

1. Disconnect BCM connector M18. Check continuity between stop lamp relay connector E39 terminal 5 and

BCM connector M18 terminal 27.

Is the inspection result normal?

YES

>> GO TO 5.

NO

>> Repair or replace damaged parts.

5.

CHECK HARNESS BETWEEN STOP LAMP SWITCH AND STOP LAMP RELAY

Check continuity between stop lamp relay connector E39 terminal 2 and stop lamp switch connector E38 ter-

minal 1.

Is the inspection result normal?

YES

>> GO TO 6.

NO

>> Repair or replace damaged parts.

6.

CHECK POWER SOURCE (STOP LAMP RELAY)

Check voltage between stop lamp relay connector E39 terminal 3 and ground.

Is the inspection result normal?

YES

>> GO TO 7.

NO

>> Repair or replace damaged parts.

7.

CHECK HARNESS BETWEEN BCM AND CVT SHIFT SELECTOR FOR OPEN

1. Disconnect CVT shift selector connector and BCM connector M80.

2. Check continuity between BCM connector M80 terminal 108 and CVT shift selector connector M78 termi-

nal 3.

Is the inspection result normal?

YES

>> GO TO 8.

NO

>> Repair or replace damaged parts.

8.

CHECK HARNESS BETWEEN BCM AND CVT SHIFT SELECTOR FOR SHORT CIRCUIT

Check continuity between BCM connector M80 terminal 108 and ground.

BCM

stop lamp relay

Continuity

Connector

Terminal

Connector

Terminal

M18

27

E39 5

Yes

Stop lamp switch

Stop lamp relay

Continuity

Connector

Terminal

Connector

Terminal

E38

2

E39 1

Yes

Stop lamp relay

Ground

Continuity

Connector

Terminal (+)

E39

3

Battery voltage

BCM

CVT shift selector

Continuity

Connector

Terminal

Connector

Terminal

M80

108

M78

3

Yes

B26FD SHIFT LOCK SOLENOID

DLK-157

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

Is the inspection result normal?

YES

>> GO TO 9.

NO

>> Repair or replace damaged parts.

9.

CHECK GROUND CIRCUIT (CVT SHIFT SELECTOR)

Check continuity between CVT shift selector connector M78 terminal 4 and ground.

Is the inspection result normal?

YES

>> Replace CVT shift selector. Refer to

TM-189, "Removal and Installation"

.

NO

>> Repair or replace damaged parts.

BCM

Ground

Continuity

Connector

Terminal

M80

108

No

CVT shift selector

Ground

Continuity

Connector

Terminal

M78

4

Yes
