COLLISION DIAGNOSIS SR-9 < BASIC INSPECTION > C D E F G I J K L M A B SR N O P Due to varying models and option levels, not all parts listed in the chart below apply to all vehicles. WORK PROCEDURE 1. Before performing any of the following steps, ensure that all vehicle body and structural repairs have been completed. 2. Check the SRS components and the related parts using the following table. - If the front seat back assembly is damaged, the front seat back assembly must be replaced. - If the door finisher assembly is damaged, the door finisher assembly and door-mounted curtain air bag module must be replaced. 3. Perform self-diagnosis using CONSULT and “AIR BAG” warning lamp. Refer to for details. Make sure entire SRS operates properly. 4. After the work is completed, perform self-diagnosis to check that no malfunction is detected. Refer to . SRS INSPECTION (FOR SIDE AND ROLLOVER COLLISION) Part Inspection Side curtain air bag module LH If the side curtain air bag LH has NOT deployed: Check for visible signs of damage (dents, tears, deformation) of the center pillar on the colli- 2. If damaged - Remove the side curtain air bag module LH. 3. Check for visible signs of damage (tears etc.) of the side curtain air bag module LH. 4. Check harness and connectors for damage, and terminals for deformities. 5. If no damage is found, reinstall the side curtain air bag module LH with new fasteners. 6. If damaged — REPLACE the side curtain air bag module LH with new fasteners. Side curtain air bag module RH If the side curtain air bag RH has NOT deployed: Check for visible signs of damage (dents, tears, deformation) of the center pillar on the colli- 2. If damaged - Remove the side curtain air bag module RH. 3. Check for visible signs of damage (tears etc.) of the side curtain air bag module RH. 4. Check harness and connectors for damage, and terminals for deformities. 5. If no damage is found, reinstall the side curtain air bag module RH with new fasteners. 6. If damaged — REPLACE the side curtain air bag module RH with new fasteners. Front side air bag module LH If the front LH side air bag has NOT deployed: Check for visible signs of damage (dents, tears, deformation) of the seat back on the collision 2. Check harness and connectors for damage, and terminals for deformities. 3. If damaged — REPLACE the front seatback assembly LH. Front side air bag module RH If the front side air bag RH has NOT deployed: Check for visible signs of damage (dents, tears, deformation) of the seat back on the collision 2. Check harness and connectors for damage, and terminals for deformities. 3. If damaged — REPLACE the front seatback assembly RH. Side air bag (satellite) sensor (LH If none of the SRS components have been activated: Remove the side air bag (satellite) sensor (LH or RH) on the collision side. Check harness 2. Check for visible signs of damage (dents, cracks, deformation) of the side air bag (satellite) 3. Install the side air bag (satellite) sensor (LH or RH) to check fit. 4. If no damage is found, reinstall the side sir bag (satellite) sensor (LH or RH) with new fasten- 5. If damaged — REPLACE the side air bag (satellite) sensor (LH or RH) with new fasteners. Door (satellite) sensor (LH or RH) If none of the SRS components have been activated: 1. Remove the door (satellite) sensor (LH or RH) on the collision side. Check harness connec- 2. Check for visible signs of damage (dents, cracks, deformation) of the door (satellite) sensor 3. Install the door (satellite) sensor (LH or RH) to check fit. 4. If no damage is found, reinstall the door (satellite) sensor (LH or RH) with new fasteners. 5. If damaged — REPLACE the door (satellite) sensor (LH or RH) with new fasteners. |
