SE-70 < SYMPTOM DIAGNOSIS > CLIMATE CONTROLLED SEAT SYSTEM SYMPTOM DIAGNOSIS CLIMATE CONTROLLED SEAT SYSTEM Symptom Table INFOID:0000000009176494 Symptom Inspection item Climate controlled seat inoperative. Power supply and ground circuit SE-49, "CLIMATE CONTROLLED SEAT CONTROL UNIT : Diagnosis . Climate controlled seat blower motor inoperative. Climate controlled seat blower motor . Seat cushion thermal electric device inoperative. Seat cushion thermal electric device . Seatback thermal electric device inoperative. Seatback thermal electric device . Climate controlled seat switch LO, MED or HI in- Climate controlled seat switch . Climate controlled seat switch indicator inopera- Climate controlled seat switch indicator . Climate controlled seat Climate controlled seat Malfunction caused by electrical issue. Check the following: Refer to • Seatback thermal electric device. Refer to • Climate controlled seat blower motor. Refer to Climate controlled seat Malfunction caused by mechanical issue. Check the following: |
