FSU-8
< PERIODIC MAINTENANCE >
WHEEL ALIGNMENT
WHEEL ALIGNMENT
Inspection
INFOID:0000000005514318
DESCRIPTION
CAUTION:
• Camber, caster, kingpin inclination angles cannot be adjusted.
• If camber, caster, or kingpin inclination angle is outside the standard, check front suspension parts
for wear and damage. Replace suspect parts if a malfunction is detected.
• Kingpin inclination angle is reference value, no inspection is required.
• Measure wheel alignment under unladen conditions.
NOTE:
“Unladen conditions” means that fuel, engine coolant, and lubricant are full. Spare tire, jack, hand tools and
mats are in designated positions.
PRELIMINARY CHECK
Check the following:
• Tires for improper air pressure and wear.
• Road wheels for runout. Refer to
WT-55, "Inspection"
.
• Wheel bearing axial end play. Refer to
FAX-8, "Inspection"
(2WD),
FAX-35, "Inspection"
(AWD).
• Transverse link ball joint axial end play. Refer to
FSU-12, "Inspection"
.
• Strut operation.
• Each mounting part of axle and suspension for looseness and deformation.
• Each of suspension member, shock absorber, upper link and transverse link for cracks, deformation and
other damage.
• Vehicle height (posture).
GENERAL INFORMATION AND RECOMMENDATIONS
• A four-wheel thrust alignment should be performed.
- This type of alignment is recommended for any NISSAN/INFINITI vehicle.
- The four-wheel “thrust” process helps ensure that the vehicle is properly aligned and the steering wheel is
centered.
- The alignment rack itself should be capable of accepting any NISSAN/INFINITI vehicle.
- The rack should be checked to ensure that it is level.
• Make sure the machine is properly calibrated.
- Your alignment equipment should be regularly calibrated in order to give correct information.
- Check with the manufacturer of your specific equipment for their recommended Service/Calibration Sched-
ule.
ALIGNMENT PROCESS
IMPORTANT:
Use only the alignment specifications listed in this Service Manual.
• When displaying the alignment settings, many alignment machines use “indicators”: (Green/red, plus or
minus, Go/No Go). Never use these indicators.
- The alignment specifications programmed into your machine that operate these indicators may not be cor-
rect.
- This may result in an ERROR.
• Some newer alignment machines are equipped with an “optional Rolling Compensation” method to “com-
pensate” the sensors (alignment targets or head units). Never use this “Rolling Compensation” method.
- Use the “Jacking Compensation Method”. After installing the alignment targets or head units, raise the vehi-
cle and rotate the wheels 1/2 turn both ways.
- See Instructions in the alignment machine you're using for more information on this.
