AV

SATELLITE RADIO TUNER

AV-395

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

JCNWM3210GB

AV-396

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

IPOD ADAPTER

IPOD ADAPTER

Reference Values

INFOID:0000000005528598

TERMINAL LAYOUT

PHYSICAL VALUES

JSNIA0618ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(BR)

13

(L)

iPod sound signal LH

Output

Ignition

switch

ON

When iPod mode is select-
ed.

2

(R)

14

(W)

iPod sound signal RH

Output

Ignition

switch

ON

When iPod mode is select-
ed.

3

(R)

Ground

ACC power supply

Input

Ignition

switch

ACC

—

Battery voltage

4

(L)

—

AV communication signal
(L)

Input/

Output

—

—

—

5

(Y)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

8

(W)

Ground

iPod battery charge

Output

Ignition

switch

ON

Connected to iPod

®

.

12.0 V

SKIB3609E

SKIB3609E

AV

IPOD ADAPTER

AV-397

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

Wiring Diagram - BOSE AUDIO WITHOUT NAVIGATION WITHOUT DVD ENTER-

9

(G)

Ground

Communication signal

(iPod adapter

→

iPod

®

)

Output

Ignition

switch

ON

The wave pattern is dis-
played just after iPod con-
nection.

NOTE:
After the wave pattern display,
the value continues Approx 3.3 V

10

(R)

Ground

Communication signal

(iPod

®

→

iPod adapter)

Input

Ignition

switch

ON

Connected to iPod

®

.

11

(R)

Ground

ACCESSORY-IDENTIFY

—

Ignition

switch

ON

Connected to iPod

®

.

0 V

12

(V)

23

(R)

iPod sound signal RH

Input

Ignition

switch

ON

When iPod mode is select-
ed.

15

—

Shield

—

—

—

—

16

(R)

—

AV communication signal
(H)

Input/

Output

—

—

—

17

Ground

Ground

—

Ignition

switch

ON

—



0  V

19

—

Shield

—

—

—

—

21

(L)

Ground

iPod connection recogni-
tion signal

Input

Ignition

switch

ON

Not connected to iPod

®

.

4.0 V

Connected to iPod

®

.

0 V

22

(BR)

Ground

ACCESSORY-DETECT

—

Ignition

switch

ON

Connected to iPod

®

.

0 V

24

(LG)

23

(R)

iPod sound signal LH

Input

Ignition

switch

ON

When iPod mode is select-
ed.

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

JPNIA0462GB

JPNIA0462GB

SKIB3609E

SKIB3609E

AV-398

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

IPOD ADAPTER

TAINMENT SYSTEM -

INFOID:0000000005528599

NOTE:
In this section, PRESET SWITCH and MULTIFUNCTION SWITCH are written as the MULTIFUNCTION
SWITCH.

JCNWM3177GB
