EXL-204 < SYSTEM DESCRIPTION > [HALOGEN TYPE] FRONT FOG LAMP SYSTEM Component Parts Location INFOID:0000000009723003 Component Description INFOID:0000000009723004 1. Front fog lamp 2. Combination switch 3. IPDM E/R 4. BCM A. Engine room (LH) B. Behind the combination meter JPLIA0843ZZ Part Description BCM • Detects each switch condition by the combination switch reading function. IPDM E/R Controls the integrated relay and supplies voltage to the load according to the request Combination switch |
