EM-118 < UNIT DISASSEMBLY AND ASSEMBLY > CYLINDER HEAD a. Apply new engine oil on valve oil seal joint and seal lip. b. Install with the valve oil seal drift [SST: KV10115600 (J-38958)] 4. Install valve spring seat. 5. Install valve. NOTE: 6. Install valve spring (uneven pitch type). (valve spring seat side). 7. Install valve spring retainer. 8. Install valve collet. KV10116200 (J-26336-A)] (A), the attachment [SST: CAUTION: When working, take care not to damage valve lifter holes. • Tap valve stem edge lightly with plastic hammer after installa- tion to check its installed condition. 9. Install valve lifter. 10. Install spark plug tube. • Press-fit spark plug tube as follows: a. Remove old liquid gasket adhering to cylinder head mounting hole. b. Apply sealant to area within approximately 12 mm (0.47 in) from edge of spark plug tube press-fit side. Chemical Products and Sealants" . Intake and exhaust : 14.3 - 14.9 mm (0.563 - 0.587 in) JPBIA0178ZZ A : Wide pitch B : Narrow pitch C : Paint mark : Cylinder head side Paint mark color: Blue JPBIA0179ZZ JPBIA0180ZZ |
