EM-78 < UNIT REMOVAL AND INSTALLATION > ENGINE ASSEMBLY a. Tighten the bolt No. 3 as shown in the figure. (temporarily) b. Tighten the bolts in numerical order as shown in the figure. 5. Install the engine mounting insulator (LH) to the transaxle as follows: a. Tighten the bolt No. 3 as shown in the figure. (temporarily) b. Tighten the bolts in numerical order as shown in the figure. 6. Install the engine mounting insulator (front) to the front suspension member as follows: a. Tighten the bolt No. 3 as shown in the figure. (temporarily) b. Tighten the bolts in numerical order as shown in the figure. 7. Install the engine mounting insulator (rear) to the front suspension member as follows: a. Tighten the bolt No. 3 as shown in the figure. (temporarily) b. Tighten the bolts in numerical order as shown in the figure. 8. Install the engine mounting stay (rear) as follows: : Engine front JPBIA1733ZZ : Vehicle front JPBIA1734ZZ : Vehicle front JPBIA1735ZZ : Vehicle front JPBIA1736ZZ |
