EC-194 < DTC/CIRCUIT DIAGNOSIS > [VQ35DE] P0127 IAT SENSOR P0127 IAT SENSOR Description INFOID:0000000009719938 The intake air temperature sensor is built-into the mass air flow sen- <Reference data> *: These data are reference values and are measured between ECM terminals 50 DTC Logic INFOID:0000000009719939 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1. PRECONDITIONING If DTC Confirmation Procedure has been previously conducted, always perform the following before conduct- Turn ignition switch OFF and wait at least 10 seconds. 2. Turn ignition switch ON. 3. Turn ignition switch OFF and wait at least 10 seconds. TESTING CONDITION: >> GO TO 2. 2. PERFORM DTC CONFIRMATION PROCEDURE With CONSULT 1. Wait until engine coolant temperature is less than 96 ° C (205 ° F) - Turn ignition switch ON. - Select “DATA MONITOR” mode with CONSULT. - Check the engine coolant temperature. PBIA9559J Intake air temperature [ ° C ( ° F)] Voltage* (V) Resistance (k Ω ) 25 (77) 3.3 1.800 - 2.200 80 (176) 1.2 0.283 - 0.359 SEF012P DTC No. Trouble diagnosis name DTC detecting condition Possible cause P0127 Intake air temperature Rationally incorrect voltage from the sensor is • Harness or connectors (The sensor circuit is open or shorted) • Intake air temperature sensor |
