AV-342

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITH NAVIGATION]

DISPLAY UNIT

DISPLAY UNIT

Reference Value

INFOID:0000000009721854

TERMINAL LAYOUT

PHYSICAL VALUES

JSNIA2241ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

6

—

Shield

—

—

—

—

7

—

Shield

—

—

—

—

8

(R)

Ground

Camera image signal

Input

Ignition

switch

ON

At camera image is dis-
played.

9

(G)

Ground

Communication signal
(DISP

→

CONT)

Output

Ignition

switch

ON

When adjusting display
brightness.

10

(R)

Ground

Communication signal
(CONT

→

DISP)

Input

Ignition

switch

ON

When adjusting display
brightness.

11

(Y)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

12

(B)

Ground

Ground

—

Ignition

switch

ON

—

0  V

SKIB2251J

PKIB5039J

PKIB5039J

AV

DISPLAY UNIT

AV-343

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

18

(GR)

Ground

Composite image signal

Input

Ignition

switch

ON

At DVD image is displayed.

19

(BR)

Ground

Composite image signal
ground

—

Ignition

switch

ON

—

0  V

22

—

Shield

—

—

—

—

23

(W)

Ground

ACC power supply

Input

Ignition

switch

ACC

—

Battery voltage

27

—

RGB digital image signal
(

−

)

Input

—

—

—

28

—

RGB digital image signal
(+)

Input

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB2251J

AV-344

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITH NAVIGATION]

BOSE AMP.

BOSE AMP.

Reference Values

INFOID:0000000009721855

TERMINAL LAYOUT

PHYSICAL VALUES

JSNIA1223ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(LG)

2

(V)

Sound signal front squawk-
er LH

Output

Ignition

switch

ON

Sound output

4

(P)

3

(L)

Sound signal front squawk-
er RH

Output

Ignition

switch

ON

Sound output

7

(B)

Ground

Ground

—

Ignition

switch

ON

—

0  V

10

(SB)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

11

(GR)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

12

(B)

Ground

Ground

—

Ignition

switch

ON

—

0  V

13

(GR)

8

(BR)

Sound signal woofer

Output

Ignition

switch

ON

Sound output

SKIB3609E

SKIB3609E

SKIB3609E

AV

BOSE AMP.

AV-345

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

14

(L)

9

(O)

Sound signal rear door
speaker RH

Output

Ignition

switch

ON

Sound output

16

(GR)

17

(BR)

Sound signal rear speaker

Output

Ignition

switch

ON

Sound output

18

(W)

19

(B)

Sound signal front door
speaker LH

Output

Ignition

switch

ON

Sound output

20

(SB)

Ground

Amp. ON signal

Input

Ignition

switch

ACC

—

12.0  V

24

(GR/V)

23

(W/L)

Sound signal rear LH

Input

Ignition

switch

ON

Sound output

26

(GR/V)

25

(W/L)

Sound signal rear RH

Input

Ignition

switch

ON

Sound output

28

(G)

15

(R)

Sound signal rear door
speaker LH

Output

Ignition

switch

ON

Sound output

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E
