BCS-64
< ECU DIAGNOSIS INFORMATION >
BCM
47
(G)
Ground
Rain sensor serial
link
Input/
Output
Power position OFF
12 V
Power position ON
8.7 V
48
(L)
Ground
CAN-H (CAN com-
munication circuit 2)
Input/
Output
—
—
49
(R)
Ground
CAN-L (CAN com-
munication circuit 2)
Input/
Output
—
—
50
(BG)
Ground
Door lock and unlock
switch LOCK
Input
Door lock and
unlock switch
NEUTRAL position
9 – 16 V
LOCK position
0 V
51
(Y)
Ground
Hazard switch
Input
Hazard switch
OFF
9 – 16 V
ON
0 V
57
(L)
Ground
Detention switch
power supply
Output
Power position
ACC or ON
9 – 16 V
OFF
0 – 0.5 V
60
(R)
Ground
Headlamp washer
switch
Input
Headlamp
washer switch
Pressed
0 V
Not pressed
9 – 16 V
63
(G)
Ground
Power window relay
control
Output
Power position
OFF or ACC
9 – 16 V
ON
0 – 0.5 V
64
(LA/R)
Ground
Rear window defog-
ger relay control
Output
Rear window
defogger
Not activated
9 – 16 V
Activated
0 – 1.5 V
65
(BR)
Ground
ACC relay control
Output
Power position
OFF
9 – 16 V
ACC or ON
0 – 0.5 V
67
(Y)
Ground
Ignition relay (J/B)
control
Output
Power position
OFF or ACC
9 – 16 V
ON
0 – 0.5 V
68
(LA/W)
Ground
Blower relay control
Output
Power position
OFF or ACC
9 – 16 V
ON
0 – 0.5 V
Terminal No.
(Wire color)
Description
Condition
Value
(Approx.)
+
−
Signal name
Input/
Output
JPMIA0156GB
