COMPONENT PARTS ECK-17 < SYSTEM DESCRIPTION > [K9K] C D E F G H I J K L M A ECK N P O <Reference data> Turbocharger Boost Sensor INFOID:0000000010289589 The turbocharger boost sensor detects intake manifold pressure. Intake Air Temperature Sensor 2 INFOID:0000000010289590 The Intake Air Temperature (IAT) Sensor 2 is built-into the Turbocharger Boost Pressure Sensor. The sensor <Reference data> Engine Coolant Temperature Sensor INFOID:0000000010289592 The engine coolant temperature (ECT) sensor is used to detect the engine coolant temperature. <Reference data> Fuel Injector INFOID:0000000010289593 This injector is a magnetic type injector. It has a code exhibiting unique characteristics, and fuel injection quan- FPCM (Fuel Pump Control Module) INFOID:0000000010501740 FPCM (Fuel Pump Control Module) controls fuel pump discharge rate according to the actual fuel require- High Pressure Fuel Pump INFOID:0000000010289594 High Pressure Fuel Pump is operated by high pressure fuel pump drive pinion, installed at camshaft. The high Intake air temperature ° C ( ° F) Resistance (Approx.) k Ω − 10 (14) 8.716 – 9.689 10 (50) 3.553 – 3.875 20 (68) 2.353 – 2.543 30 (86) 1.613 – 1.729 50 (122) 0.794 – 0.839 Intake air temperature ° C ( ° F) Resistance (Approx.) k Ω − 10 (14) 9.395 – 9.775 10 (50) 3.791 – 3.927 20 (68) 2.416 – 2.583 30 (86) 1.706 – 1.760 50 (122) 0.833 – 0.857 Engine coolant temperature ° C ( ° F) Resistance (Approx.) k Ω − 10 (14) 11.33 – 13.59 25 (77) 2.140 – 2.364 50 (122) 0.771 – 0.849 80 (176) 0.275 – 0.291 110 (230) 0.112 – 0.117 |
