ECK-40 < SYSTEM DESCRIPTION > [K9K] SYSTEM Input/ Output Transmits/Receives component Signal name Description Input Crankshaft position sensor Crankshaft position sensor signal Detects an engine speed. Engine coolant temperature Engine coolant temperature sensor signal Detects an engine coolant tem- Clutch pedal position switch Clutch pedal position switch signal Detects the clutch pedal is de- Clutch pedal interlock switch Clutch pedal interlock switch signal Detects the clutch pedal is de- Neutral position switch Neutral position switch signal Detects the neutral position. Atmospheric pressure sensor Atmospheric pressure sensor signal Detects an atmospheric pres- IPDM E/R CAN communica- Stop/Start permit signal Detects IPDM E/R is ready to op- GY MANAGEMENT SYSTEM : . Battery current signal Detects battery current. Neutral position switch signal Detects the neutral position. Hood switch signal Detects engine hood status. Battery current sensor malfunc- Detects the battery current sen- BCM CAN communica- Ignition switch status signal Detects ignition switch status. Door switch signal Detects the status of driver side Stop/Start OFF switch signal Detects stop/start OFF switch ABS actuator and electric unit CAN communica- Vehicle speed signal Detects vehicle speed. Brake booster pressure sensor Detects a pressure in brake ABS operation signal Detects ABS operation. ESP operation signal Detects ESP operation. EPS control unit CAN communica- EPS torque signal Detects an operational state of Stop/Start inhibit signal Receives the intelligent parking A/C auto amp. CAN communica- Stop/Start permit signal Detects the air conditioning sys- HAC-32, "STOP/START SYS- Combination meter CAN communica- Seat belt buckle switch signal Detects driver is sitting on the DC/DC converter LIN communication Operation status signal Detects an operational state of Diagnosis signal Detects DC/DC converter mal- |
