ANTENNA FEEDER

Feeder Layout

INFOID:0000000010435758

ANTENNA FEEDER LAYOUT

1.

Antenna base (antenna amp. and
satellite antenna)

2.

Rod Antenna

3.

M394

4.

M399

E1NIA0073ZZ
