SYSTEM EXL-25 < SYSTEM DESCRIPTION > [LED HEADLAMP] C D E F G H I J K M A B EXL N O P TURN SIGNAL AND HAZARD WARNING LAMP SYSTEM TURN SIGNAL AND HAZARD WARNING LAMP SYSTEM : System Description INFOID:0000000010338659 SYSTEM DIAGRAM OUTLINE Turn signal lamp and hazard warning lamp is controlled by combination switch reading function and the flasher TURN SIGNAL LAMP OPERATION • BCM detects the combination switch condition by the combination switch reading function. signal switch is in the right (left) position. BCM blinks the turn signal lamp. HAZARD WARNING LAMP OPERATION BCM supplies voltage to both turn signal lamp circuits when the hazard switch is ON. BCM blinks the hazard TURN SIGNAL INDICATOR LAMP AND TURN SIGNAL OPERATION • BCM transmits the turn indicator signal to the combination meter using CAN communication while the turn signal lamp and the hazard warning lamp are operating. • Combination meter outputs the turn signal sound with the integrated buzzer while blinking the turn signal indicator lamp according to the turn indicator signal. 3-TIME FLASHER FUNCTION • By a short touch of the turn signal lever, BCM blinks the turn signal lamps 3 times in the selected direction. flasher function operation. NOTE: Function (BCM - FLASHER) (LED Headlamp)" . HIGH FLASHER OPERATION • BCM detects the turn signal lamp circuit status from the current value. nal lamp operating. B20DB HEIGHT SENS INITIALIZE NOT DONE [MISSING Right and left headlamp aiming motors fix at the initial [NOT CON- DTC CONSULT display description Fail-safe JMLIA5232GB |
