RADIATOR CO-19 < REMOVAL AND INSTALLATION > [HRA2DDT] C D E F G H I J K L M A CO N P O *: Refer to the illustrations for the specific position each hose clamp tab. • The angle (b) created by the hose clamp pawl and the specified line (A) must be within ± 30 as shown in the figure. • To install hose clamps (1), check that the dimension (A) from the end of the hose clamp on the radiator hose to the hose clamp is Inspection INFOID:0000000010416349 INSPECTION AFTER INSTALLATION • Check for leakage of engine coolant using the radiator cap tester adapter (commercial service tool) and the radiator cap tester (commercial service tool). Refer to • Start and warm up the engine. Check visually that there is no leakage of engine coolant. Radiator hose Hose end Paint mark Position of hose clamp* Radiator hose (upper) Radiator side Upper A Engine side Upper B Radiator hose (lower) Radiator side Lower C Engine side Upper D E. View E f. 45 ° g. 45 ° : Vehicle upper JPBIA3911ZZ JPBIA4295ZZ Dimension “A” : 3 mm (0.12 in) JSBIA0241ZZ |
