HOOD LOCK DLK-813 < REMOVAL AND INSTALLATION > [TYPE 5] C D E F G H I J L M A B DLK N O P • Check that cable is not offset from the positioning grommet, and apply the sealant to the grommet (at * mark) properly. • After installation, perform hood fitting adjustment. Refer to DLK-784, "HOOD ASSEMBLY : Adjust- • After installation, perform hood lock control inspection. Refer to . HOOD SAFETY HOOK HOOD SAFETY HOOK : Removal and Installation INFOID:0000000010678820 REMOVAL Remove mounting nuts, and then remove hood lock secondary assembly. INSTALLATION Note the following item, and install in the reverse order of removal. CAUTION: After installation, perform hood lock control inspection. Refer to . Inspection INFOID:0000000010678821 NOTE: Check that hood opener operating is condition 49 N (5.0 kg, 11.0 lb) or below. 2. Check that secondary latch is securely engaged with secondary striker from the dead load of the hood 3. Check that primary latch is securely engaged with primary striker when hood assembly is closed [free-fall CAUTION: Never free-fall hood assembly from a height of 300 (11.811 in) mm or more. 4. While operating hood opener, carefully check that the front end of hood is raised by approximately 20.0 5. Check that secondary latch is properly engaged with secondary striker [4.0 mm (0.157 in)]. 6. Check the hood lock lubrication condition. If necessary, apply PIIB5801E : Body grease JMKIB1164ZZ |
