FRONT DOOR DLK-617 < REMOVAL AND INSTALLATION > [TYPE 4] C D E F G H I J L M A B DLK N O P CAUTION: • Perform work with 2 workers, because of its heavy weight. tect door and body. 1. Remove front fender. Refer to DLK-612, "Removal and Installation" 2. Remove front door assembly. Refer to DLK-614, "DOOR ASSEMBLY : Removal and Installation" . 3. Remove front door hinge mounting bolts (body side), and then remove front door hinge. INSTALLATION Note the following items, and install in the reverse order of removal. CAUTION: • Apply anticorrosive agent onto the mounting surface. DLK-615, "DOOR ASSEMBLY : Adjust- • After installation, apply touch-up paint (the body color) onto the head of door hinge mounting nuts. DOOR HINGE : Inspection INFOID:0000000010479422 Check door hinge rotating part for poor lubrication. Apply body DOOR CHECK LINK DOOR CHECK LINK : Removal and Installation INFOID:0000000010479423 REMOVAL 1. Fully close the front door glass. 2. Remove front door finisher. Refer to INT-12, "FRONT DOOR FINISHER : Removal and Installation" . 3. Remove front door speaker. a. Disconnect front door speaker harness connector. b. Remove front door speaker mounting bolts, and then remove front door speaker. 4. Remove check link mounting bolts of vehicle body side. 5. Remove check link mounting bolts of door side. 6. Take door check link out from the hole of door panel. INSTALLATION Note the following items, and install in the reverse order of removal. CAUTION: • Check front door open/close operation after installation. : Body grease JMKIB0321ZZ |
