SYSTEM (INTELLIGENT KEY SYSTEM)
DLK-41
< SYSTEM DESCRIPTION >
[TYPE 1]
C
D
E
F
G
H
I
J
L
M
A
B
DLK
N
O
P
*:If the door closing impact shocks the door lock knob, or contacts against baggage with the door lock knob might activate the door locks
accidentally but unlock operation is perform in these cases.
CAUTION:
• The above function operates when the Intelligent Key is inside the vehicle. However, there may be
times when the Intelligent Key cannot be detected, and this function does not operate when the Intel-
ligent Key is on the instrument panel, rear parcel shelf, or in the glove box. Also, this system some-
times does not operate if the Intelligent Key is in the door pocket for the open door.
WARNING FUNCTION
WARNING FUNCTION : System Description
INFOID:0000000010434557
OPERATION DESCRIPTION
The warning function are as per the following items and are given to the user as warning information and
warnings using combinations of Intelligent Key warning buzzer, combination meter buzzer and information dis-
play in combination meter.
• Intelligent Key system malfunction
• OFF position warning
• P position warning
• Take away warning
• Door lock operation warning
• Engine start information
• Intelligent Key low battery warning
• Key ID verification information
• Steering lock information
• Key ID warning
OPERATION CONDITION
Operation condition of warning and information is as per the following table.
Key remainder func-
tion
Operation condition
Operation
Driver side door
opened
Right after door is locked by door lock/unlock switch or driver door lock
knob operation under the following conditions
• Ignition switch is in the OFF position
• Intelligent Key is inside the vehicle
• Driver side door is opened
All doors unlock
Driver side door
closed*
Right after driver side door is closed under the following conditions
• Intelligent Key is inside the vehicle
• Driver side door is opened
• Driver side door is in unlock state
All doors unlock
Door is open or closed
Right after all doors are closed under the following conditions
• Intelligent Key is inside the vehicle
• Any door is opened
• All doors are locked.
• All doors unlock
• Honk Intelligent Key warn-
ing buzzer
Warning/Information functions
Operation procedure
Intelligent Key system malfunction
A malfunction is detected on BCM and key warning lamp turns ON
OFF position warning
When condition A or B is satisfied
• Condition A
- Turn ignition switch from ON to OFF while door is open
• Condition B
- Intelligent Key backside is contacted to push-button ignition switch while
brake pedal is depressed and ignition switch is LOCK or OFF (When the In-
telligent Key battery is discharged)
- Door switch (driver side): ON (Door is open)
P position warning*
For internal
• Shift position: Except P position
• Engine is running to stopped (Ignition switch is ON to OFF)
For external
• P position warning (For internal) operates
• Door switch: ON to OFF (Door is open to close)
• Intelligent Key cannot be detected inside the vehicle
