EXL-200 < SYMPTOM DIAGNOSIS > [HALOGEN TYPE] PARKING, LICENSE PLATE, SIDE MARKER AND TAIL LAMPS ARE NOT TURNED ON PARKING, LICENSE PLATE, SIDE MARKER AND TAIL LAMPS ARE NOT Description INFOID:0000000012201773 The parking, license plate, side marker and tail lamps are not turned ON in any condition. Diagnosis Procedure INFOID:0000000012201774 1. COMBINATION SWITCH INSPECTION Check combination switch. Refer to Is the inspection result normal? YES >> GO TO 2. NO >> Repair or replace the malfunctioning part. 2. CHECK POSITION LIGHT REQUEST SIGNAL With CONSULT 1. Turn ignition switch ON. 2. Select “TAIL & CLR REQ” in “Data Monitor” mode of “IPDM E/R” using CONSULT. 3. With operating the lighting switch, check the monitor status. Is the inspection result normal? YES >> Perform the tail lamp diagnosis. Refer to EXL-171, "Component Function Check" . NO >> Replace BCM. Refer to BCS-94, "Removal and Installation" Monitor item Condition Monitor status TAIL & CLR REQ Lighting switch 1ST On OFF Off |
