DLK-128 < REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM] HOOD If the clearance and the surface height are out of specification, adjust them according to the procedures shown below. Unit: mm (in) 1. Remove front center grille. Refer to EXT-26, "Removal and Installation" 2. Remove hood lock assembly. EXT-17, "Removal and Installation" . 4. Remove front combination lamp (LH and RH). Refer to EXL-100, "Removal and Installation" EXL-211, "Removal and Installation" (halogen type). 5. Remove front fender assembly (LH and RH). Refer to DLK-133, "Removal and Installation" 6. Loosen hood hinge mounting bolts. bumper fascia. 8. Adjust the clearance of hood assembly, front fender assembly (LH and RH), front combination lamp (LH and RH) and front bumper fascia according to the specified value, by moving hood hinge (body side). 9. Temporarily tighten hood hinge (LH and RH). RH). 11. Tighten hood hinge (LH and RH) to the specified torque. DLK-133, "Removal and Installation" . 13. Install front combination lamp (LH and RH). Refer to EXL-100, "Removal and Installation" EXL-211, "Removal and Installation" (halogen type). 14. Install front bumper fascia. Refer to EXT-17, "Removal and Installation" . 15. Adjust the surface height of hood assembly, front fender assembly, and front combination lamp according to the specified value, by rotating hood bumper rubber. 16. Position hood lock assembly and engage hood striker. Check hood lock assembly and hood striker for looseness. 17. Move hood lock assembly laterally until the center of hood striker and hood lock assembly are vertical when viewed from the front. 18. After adjustment, tighten lock bolts to the specified torque. hood assembly. 21. Check that primary latch is securely engaged with primary hood striker when hood assembly is closed [free-fall from approximately 200 mm (7.874 in) height]. CAUTION: Never free-fall hood assembly from a height of 300 (11.811 in) mm or more. 22. Install front center grille. Refer to EXT-26, "Removal and Installation" CAUTION: After installation, apply touch-up paint (the body color) onto the heads of hood hinge mounting bolts and nuts. Portion Standard Difference (RH/LH, MAX) Hood – Front A – A E Clearance 2.0 – 6.0 (0.079 – 0.236) < 2.5 (0.098) F Surface height (-2.0) – (+2.0) [(-0.079) – (+0.079)] < 2.5 (0.098) Hood – Front combi- B – B G Clearance 2.0 – 6.0 (0.079 – 0.236) < 2.5 (0.098) Hood – Front combi- C – C H Clearance 2.0 – 6.0 (0.079 – 0.236) < 2.5 (0.098) Hood – Front fender D – D I Clearance 2.5 – 4.5 (0.098 – 0.177) < 1.5 (0.059) J Surface height (-2.0) – (0.0) [(-0.079) – (0.000)] < 1.5 (0.059) |
