Mitsubishi L200 (2018 year). Instruction

Folder Repeat Playback

Hold down the 1RPT key.

Repeat playback of the tracks within the fold-
er currently being played.

NOTE

Pressing again will cancel.

Even if the file is selected, folder repeat
playback will not be cancelled.

Random Playback (RDM)

Press the 2RDM key.

Play the tracks in the folder in a random or-
der.

NOTE

Pressing again will cancel.

Folder Random Playback

Hold down the 2RDM key.

Play all tracks in folders on the disc in a ran-
dom order.

NOTE

Pressing again will cancel.

Scan Playback (SCAN)

Press the SCAN key.

Play the first 10 seconds of each of the tracks
in the folder currently being played in order.

Search Tracks

Search folders and files, and select a track.

1. Turn the /SEL key to select the folder.
2. Press the /SEL key.

Files within the selected folder are dis-
played.

3. Turn the /SEL key to select the file.
4. Press the /SEL key.

This plays the selected file (track).

NOTE

While the folder is selected, press the 6
key to cancel track search mode.

If there is no operation for 10 seconds after
selecting the folder, then track search mode
will be cancelled.

NOTE

Select the folder, and hold down the

/SEL

key to start playback from the first track in
that folder.

While the file is selected, press the 6

key

to return to the previous operation.

While the file is selected, hold down the 6

key to cancel track search mode.

If there is no operation for five seconds after
selecting the file, that file is played back.

Disc operations such as selecting a track will
cancel track search mode.

Listen to an iPod

E00738001433

By connecting commercially-available iPod/
iPhone devices to this product, you can play
back tracks on these through the product.

CAUTION

Do not leave the iPod/iPhone unattended in
the vehicle.

Never hold these devices in your hand to op-
erate while driving, as this is dangerous.

No indemnification for data loss resulting
when the iPod/iPhone is connected to the
product will be possible.

Depending on how the devices are handled,
audio files being damaged or lost, therefore
it is recommended that data be backed up.

Listen to an iPod

7-56

OKTE18E1

For pleasant driving

NOTE

Depending on the generation, model, or soft-
ware version of the iPod/iPhone, playback
on this product may not be possible. (→P.
7-18) Additionally, playback as explained in
this document may not be possible.

In some countries, for vehicles with a Blue-
tooth

2.0 interface, the types of devices that

can be connected may vary.
For  details,  access  the  MITSUBISHI
MOTORS website.
Please read and agree to the “Warning about
Links  to  the  Web  Sites  of  Other  Compa-
nies”.  The  websites  mentioned  above  may
connect  you  to  websites  other  than  the
MITSUBISHI MOTORS website.
http://www.mitsubishi-motors.com/en/prod-
ucts/ index.html

Usage of iPod/iPhone hardware with the lat-
est software version is recommended.

Regarding how to connect the iPod/iPhone,
refer to “How to connect an iPod” on page
7-97.

When connecting the iPod/iPhone, use a
commercially-available iPod connection ca-
ble.

Set up the device in order that no unsafe ac-
tions, such as plugging in the connection ca-
ble are taken while driving.

When inserting and removing the iPod/
iPhone, for safety’s sake first stop the vehi-
cle.

Depending on the status of the iPod/iPhone,
it may take some time until the device is rec-
ognized, or playback starts.

NOTE

Buttons on the product will not operate
while iPod/iPhone is connected.

iPod/iPhone specifications and settings may
mean that connection is not possible, or re-
sult in differences in operation or display.

Depending on audio data in the iPod/iPhone,
track information may not be displayed cor-
rectly.

Depending on the status of the vehicle and
device, the iPod/iPhone may not play back
after starting the engine.

Data containing copyright information may
not play back.

It is recommended that the iPod/iPhone
equaliser settings be set to flat.

Operate the iPod/iPhone while connected to
this product.

If  the  iPod/iPhone  is  connected  via  Blue-
tooth  as  a  Bluetooth-capable  audio  device,
then  do  not  connect  the  iPod/iPhone  using
an iPod connection cable. Connection using
both methods will result in erroneous opera-
tion.

If an iPod/iPhone does not operate correctly,
then remove the iPod/iPhone from the prod-
uct, reset, then reconnect.

Play iPod

Press the MEDIA key to set the iPod as the
source.

The selected source is indicated on the dis-
play.

Select the Track (File)

Press the

key or

key to select the

track.

This enables selection of the next or previous
track.

Fast Forward or Rewind

Hold down the 3

key or the 4

key.

Fast forward/rewind is possible.

Switch Playback Mode

Repeat playback and shuffle playback are
possible.

Repeat Playback (RPT)

Press the 1RPT key.

Repeat playback of the track currently being
played.

NOTE

Pressing again will cancel.

Shuffle Playback (RDM)

Press the 2RDM key.

Listen to an iPod

7-57

OKTE18E1

For pleasant driving

Play tracks in the category currently being
played in a random order.

NOTE

Pressing again will cancel.

Album Shuffle Playback

Hold down the 2RDM key.

Play back the album in a random order
(tracks in any order on the album).

NOTE

Pressing again will cancel.

Search Tracks

Search categories or track names, and select a
track.

1. Turn the

/SEL key to select the cate-

gory.

2. Press the

/SEL key. Categories or

tracks within the selected category are
displayed.

3. Turn the /SEL key to select the cate-

gory or track.

4. Press the /SEL key.

Repeat steps 1 to 4, and search for
tracks.
Select the track, and press the

/SEL

key to play.

NOTE

While the category (1

level) is selected,

press the 6

key to cancel track search

mode.

If there is no operation for 10 seconds after
selecting the category, then track search
mode will be cancelled.

Select the category, and hold down the

/SEL key to start playback from the first

track in that category.

While the track is selected, press the 6
key to return to the previous operation.

While the track is selected, hold down the 6

key to cancel track search mode.

If there is no operation for five seconds after
selecting the track, that file is played back.

iPod operations such as selecting a track will
cancel track search mode.

Listen to Audio Files on a
USB Device

E00736501447

By connecting commercially-available USB
devices such as USB memory to this product,
you can play back audio files on these
through the product.

CAUTION

Do not leave the USB device unattended in
the vehicle.

Never hold these devices in your hand to op-
erate while driving, as this is dangerous.

Do not use hard discs, card readers, or mem-
ory readers, as damage may occur to these or
to the data contained therein. If these are er-
roneously connected, then turn the ignition
switch to the “LOCK” position or put the
operation mode in OFF, then remove.

Because of the risk of data loss, it is recom-
mended that files be backed up.

No guarantee is made as regards damage to
the USB device, nor regarding loss or dam-
age to data contained therein.

Depending on how the devices are handled,
audio files being damaged or lost, therefore
it is recommended that data be backed up.

NOTE

Digital audio players that support the mass
storage class specifications can be connec-
ted.

For details regarding the types of USB devi-
ces that can be connected and the types of
files that can be played back in vehicles with
a Bluetooth

2.0 interface, refer to “Types

of connectable devices and supported file
specifications” on page 7-97.

Regarding how to connect USB devices, re-
fer to “How to connect a USB memory de-
vice” on page 7-96.

Listen to Audio Files on a USB Device

7-58

OKTE18E1

For pleasant driving

NOTE

When connecting a USB device, use a con-
nection cable. Failure to use a connection ca-
ble when connecting may place undue load
on, or damage the USB connector.

Set up the device in order that no unsafe ac-
tions, such as plugging in the connection ca-
ble are taken while driving.

When inserting and removing the USB de-
vice, for safety’s sake first stop the vehicle.

Do not insert other than audio devices into
the USB port. Damage to the device or
equipment may result.

Depending on the status of the USB device,
it may take some time until the device is rec-
ognized, or playback starts.

Buttons on the product will not operate
while USB device is connected.

USB device specifications and settings may
mean that connection is not possible, or re-
sult in differences in operation or display.

Depending on audio data in the USB device,
track information may not be displayed cor-
rectly.

Depending on the status of the vehicle and
device, the iPod/iPhone may not play back
after starting the engine.

Data containing copyright information may
not play back.

This product can play back MP3, WMA, and
AAC format audio files.

Depending on the type of USB device, usage
may not be possible, or functions that can be
used may be restricted.

The recommended file system for USB
memory is FAT32.

NOTE

The maximum supported capacity for USB
memory is 32GB.

Operate the USB device containing recorded
audio files while connected to this product.

Play Back of Audio Files on a

USB Device

Press the MEDIA key to set

USB as the source. The selected source is in-
dicated on the display.

Select the Track (File)

Press the

key or

key to select the

track.

This enables selection of the next or previous
track.

Fast Forward or Rewind

Hold down the 3

key or the 4

key.

Fast forward/rewind is possible.

Switch Playback Mode

Repeat playback, random playback, and scan
playback are possible.

Repeat Playback (RPT)

Press the 1RPT key.

Repeat playback of the track currently being
played.

NOTE

Pressing again will cancel.

Selecting a file will cancel this.

Folder Repeat Playback

Hold down the 1RPT key.

Repeat playback of the tracks within the fold-
er currently being played.

NOTE

Pressing again will cancel.

Even if the file is selected, folder repeat
playback will not be cancelled.

Folder

Random

Playback

(RDM)

Press the 2RDM key.

Play tracks in the folder currently being
played in a random order.

Listen to Audio Files on a USB Device

7-59

OKTE18E1

For pleasant driving

NOTE

Pressing again will cancel.

Even if the file is selected, folder random
playback will not be cancelled.

All Folder Random Playback

Hold down the 2RDM key.

Play the tracks in all folders in a random or-
der.

NOTE

Pressing again will cancel.

Even if the file is selected, all folder random
playback will not be cancelled.

Scan Playback (SCAN)

Press the PTY/SCAN key.

Play the first 10 seconds of each of the tracks
on the whole USB device in order.

NOTE

Press this button again during playback if
you wish to hear that track, and that track
will play normally.

Folder Scan Playback

Hold down the PTY/SCAN key.

Play the first 10 seconds of the first track in
each folder on the USB device in order.

NOTE

Press this button again during playback if
you wish to hear that track, and that track
will play normally.

Search Tracks

Search folders and files, and select a track.

1. Turn the /SEL key to select the folder.
2. Press the /SEL key.

Files within the selected folder are dis-
played.

3. Turn the /SEL key to select the file.
4. Press the /SEL key.

This plays the selected file (track).

NOTE

While the folder is selected, press the 6
key to cancel track search mode.

If there is no operation for 10 seconds after
selecting the folder, then track search mode
will be cancelled.

Select the folder, and hold down the

/SEL

key to start playback from the first track in
that folder.

NOTE

While the file is selected, press the 6

key

to return to the previous operation.

While the file is selected, hold down the 6

key to cancel track search mode.

If there is no operation for five seconds after
selecting the file, that file is played back.

Operations such as selecting a track will
cancel track search mode.

To play iPod/USB memory
device tracks via voice
operation (vehicles with
Bluetooth

2.0 interface)

E00770800111

Desired tracks on the iPod/USB memory de-
vice which is connected to the USB input ter-
minal  can  be  selected  and  played  via  voice
operation.
For  information  concerning  the  voice  recog-
nition  function  or  speaker  registration  func-
tion, refer to “Bluetooth® 2.0 interface*” on
page 7-76.
The  following  explains  how  to  prepare  for
voice operation and play the tracks.

To play iPod/USB memory device tracks via voice operation (vehicles with Bluetooth

2.0 interface)

7-60

OKTE18E1

For pleasant driving

Preparation for voice operation

E00770900082

To use the voice operation, press the
SPEECH button (A) first.

Type 1

Type 2

To search by artist name

E00771000022

1. Say “Play” on the main menu.

NOTE

The Bluetooth

2.0 interface starts recogniz-

ing the connected device.
If the connected device cannot be recognized
or a connection error occurs, the Bluetooth

2.0 interface starts an appropriate voice
guide. Follow the voice guide.

2. After the voice guide says “Would you

like to play by Artist, Album, Playlist or
Genre?,” say “Artist”.

NOTE

If you say “Artist <name>,” you can skip
step 3.

3. After the voice guide says “What Artist

would you like to play?,” say the artist
name.

4. If there is only one match, the system

proceeds to step 6.

5. If there are two or more matches, the

voice guide will say “More than one
match was found, would you like to play
<artist name>?” If you say “Yes,” the
system proceeds to step 6.
If you say “No,” the next matching artist
is uttered by the system.

NOTE

If you say “No” to three or all artist names
uttered by the system, the voice guide will
say “Artist not found, please try again” and
the system returns to step 2.

Search time is dependant on the number of
songs on your connected device. Devices
containing a large number of songs may take
longer to return search results.

6. After the voice guide says “Playing <ar-

tist name>,” the system creates a playlist
index for the artist.

NOTE

If  the  confirmation  function  is  active,  the
voice  guide  confirms  if  the  artist  name  is
correct.  If  the  artist  name  is  correct,  say
“Yes”.  If  not,  say  “No”.  After  the  voice
guide  says  “Artist  not  found,  please  try
again,” the system returns to step 2.

7. The system exits the voice recognition

mode and starts playback.

To search by album title

E00771100023

1. Say “Play” on the main menu.

To play iPod/USB memory device tracks via voice operation (vehicles with Bluetooth

2.0 interface)

7-61

OKTE18E1

For pleasant driving

NOTE

The Bluetooth

2.0 interface starts recogniz-

ing the connected device.
If the connected device cannot be recognized
or a connection error occurs, the Bluetooth

2.0 interface starts an appropriate voice
guide. Follow the voice guide.

2. After the voice guide says “Would you

like to play by Artist, Album, Playlist or
Genre?,” say “Album”.

NOTE

If you say “Album <title>,” you can skip
step 3.

3. After the voice guide says “What Album

would you like to play?” say the album
title.

4. If there is only one match, the system

proceeds to step 6.

5. If there are two or more matches, the

voice  guide  will  say  “More  than  one
match was found, would you like to play
<album  title>?”  If  you  say  “Yes,”  the
system proceeds to step 6.
If  you  say  “No,”  the  next  matching  al-
bum is uttered by the system.

NOTE

If you say “No” to three or all album titles
uttered by the system, the voice guide will
say “Album not found, please try again” and
the system returns to step 2.

6. After the voice guide says “Playing <al-

bum title>,” the system creates a playlist
index for the album title.

NOTE

If  the  confirmation  function  is  active,  the
voice  guide  confirms  if  the  album  title  is
correct.  If  the  album  title  is  correct,  say
“Yes”.  If  not,  say  “No”.  After  the  voice
guide  says  “Album  not  found,  please  try
again,” the system returns to step 2.

7. The system exits the voice recognition

mode and starts playback.

To search by playlist

E00771200024

1. Say “Play” on the main menu.

NOTE

The Bluetooth

2.0 interface starts recogniz-

ing the connected device.
If the connected device cannot be recognized
or a connection error occurs, the Bluetooth

2.0 interface starts an appropriate voice
guide. Follow the voice guide.

2. After the voice guide says “Would you

like to play by Artist, Album, Playlist or
Genre?,” say “Playlist”.

NOTE

If you say “Playlist <playlist>,” you can skip
step 3.
If the device has no playlist, the voice guide
will say “There are no playlists stored on de-
vice” and the system returns to step 2.

3. After the voice guide says “What Play-

list would you like to play?,” say the
playlist name.

4. If there is only one match, the system

proceeds to step 6.

5. If there are two or more matches, the

voice guide will say “More than one
match was found, would you like to play
<playlist>?” If you say “Yes,” the sys-
tem proceeds to step 6.
If you say “No,” the next matching play-
list name is uttered by the system.

To play iPod/USB memory device tracks via voice operation (vehicles with Bluetooth

2.0 interface)

7-62

OKTE18E1

For pleasant driving

NOTE

If you say “No” to three or all playlist names
uttered by the system, the voice guide will
say “Playlist not found, please try again” and
the system returns to step 2.

6. After the voice guide says “Playing

<playlist>,” the system creates an index
for the playlist.

NOTE

If  the  confirmation  function  is  active,  the
voice guide confirms if the playlist name is
correct.  If  the  playlist  name  is  correct,  say
“Yes”.  If  not,  say  “No”.  After  the  voice
guide  says  “Playlist  not  found,  please  try
again,” the system returns to step 2. Refer to
“Confirmation  function  setting”  on  page
7-79.

7. The system exits the voice recognition

mode and starts playback.

To search by genre

E00771300025

1. Say “Play” on the main menu.

NOTE

The Bluetooth

2.0 interface starts recogniz-

ing the connected device.
If the connected device cannot be recognized
or a connection error occurs, the Bluetooth

2.0 interface starts an appropriate voice
guide. Follow the voice guide.

2. After the voice guide says “Would you

like to play by Artist, Album, Playlist or
Genre?,” say “Genre”.

NOTE

If you say “Genre <type>,” you can skip
step 3.

3. After the voice guide says “What Genre

would you like to play?,” say the music
type.

4. If there is only one match, the system

proceeds to step 6.

5. If there are two or more matches, the

voice guide will say “More than one
match was found, would you like to play
<genre>?” If you say “Yes,” the system
proceeds to step 6.
If you say “No,” the next matching
genre is uttered by the system.

NOTE

If you say “No” to three or all genres uttered
by the system, the voice guide will say
“Genre not found, please try again” and the
system returns to step 2.

6. After the voice guide says “Playing

<genre>,” the system creates an index
for the genre.

NOTE

If  the  confirmation  function  is  active,  the
voice guide confirms if the genre is correct.
If the genre is correct, say “Yes”. If not, say
“No”. After the voice guide says “Genre not
found,  please  try  again,”  the  system  returns
to  step  2.  Refer  to  “Confirmation  function
setting” on page 7-79.

7. The system exits the voice recognition

mode and starts playback.

Listen to Bluetooth Audio*

E00736701322

This product can play back tracks on com-
mercially- available Bluetooth-capable audio
devices.

Listen to Bluetooth Audio*

7-63

OKTE18E1

For pleasant driving

CAUTION

Never hold these devices in your hand to op-
erate while driving, as this is dangerous.

Do not leave the Bluetooth audio device un-
attended in the vehicle.

Depending on how the devices are handled,
audio files being damaged or lost, therefore
it is recommended that data be backed up.

NOTE

Depending on the type of Bluetooth-capable
audio devices, usage may not be possible, or
functions that can be used may be restricted.

Confirm together with the user manuals for
the commercially-available Bluetooth-capa-
ble audio devices.

Depending on the type of Bluetooth-capable
audio devices, volume levels may differ.
There is the danger of loud volumes, so prior
to use, it is recommended that you turn the
volume down.
→ “Adjust Volume” (P.7-48)

Depending on the status of the Bluetooth au-
dio device, it may take some time until the
device is recognized, or playback starts.

Bluetooth audio device specifications and
settings may mean that connection is not
possible, or result in differences in operation
or display.

Depending on audio data in the Bluetooth
audio device, track information may not be
displayed correctly.

NOTE

Depending on the status of the vehicle and
device, the iPod/iPhone may not play back
after starting the engine.

Connect a Bluetooth-capable

Audio Device

Regarding how to connect your Bluetooth de-
vice, refer to “Connecting the Bluetooth® 2.0
interface and Bluetooth® device” on page
7-82.
Operation methods below describe situations
once connection has been completed.

NOTE

Play Bluetooth Audio

1. Press the MEDIA key to set Bluetooth

Audio as the source.

The selected source is indicated on the
display.

2. Press the 5

key. Bluetooth Audio

playback starts.

NOTE

Hold down the 5

key to pause.

Press the 6

key to stop.

Select the Track (File)

Press the

key or

key to select the

track.

This enables selection of the next or previous
track.

Fast Forward or Rewind

Hold down the 3

key or the 4

key.

Fast forward/rewind is possible.

Switch Playback Mode

Repeat playback, random playback, and scan
playback are possible.

Repeat Playback (RPT)

Press the 1RPT key.

Repeat playback of the track currently being
played.

Listen to Bluetooth Audio*

7-64

OKTE18E1

For pleasant driving

NOTE

Each time the 1RPT key is pressed, this
switches in the order Repeat OFF, 1 track re-
peat, All track repeat, and Repeat OFF.

Random Playback (RDM)

Press the 2RDM key.

Play the tracks in the Bluetooth Audio device
in a random order.

NOTE

Pressing again will cancel.

Scan Playback (SCAN)

Press the PTY/SCAN key.

Play the first 10 seconds of each of the tracks
on the whole Bluetooth Audio device in or-
der.

NOTE

Press this button again during playback if
you wish to hear that track, and that track
will play normally.

Listen to Bluetooth Audio*

7-65

OKTE18E1

For pleasant driving

Display Indicator

E00738101186

This explains content of the display indicator.

Change the Display Mode

E00738500053

You can change the content of the display in-
dicator.
Press the DISP key to switch the display con-
tent.

Each time the DISP key is pressed, the dis-
play content changes.

CAUTION

The operation of changing display contents
may impede safe driving, therefore check
safety before operation.

NOTE

Up to 11 characters may be displayed at one
time. To display 12 or more characters, press
the PAGE key, and subsequent characters
will be displayed.

During DAB Reception*

This switches in the order “Service name”,
“Ensemble name”, and “CH no. (CH ID)”.

NOTE

If the text information for the service name
and ensemble name cannot be obtained, then
nothing is displayed.

Display Indicator

7-66

OKTE18E1

For pleasant driving

During CD-DA playback

This switches in the order “Disc title”,
“Track title”, and “Operating status”.

NOTE

If there is no text information to display,
then “NO TITLE” is displayed.

During MP3/WMA/AAC Play-

back

This switches in the order “Folder title”,
“File title”, and “Operating status”.

NOTE

If there is no text information to display,
then “NO TITLE” is displayed.

Display the ID3tag

Hold down the DISP key.

This switches the ID3tag display.
[DISP] Each time the key is pressed, this
switches in the order “Album name”, “Track
name”, “Artist name”, “Genre name”*, and
“Operating status”.

*: Displayed when playing back audio

files on a USB device (vehicles with a
Bluetooth

2.0 interface).

NOTE

During display of the ID3tag, hold down the
DISP key to switch to the folder title dis-
play.

The genre name display may not be possible.

During iPod Playback

E00738900028

This switches in the order “Albums”, “Track
name”, “Artist name”, “Genre name”*, and
“Operating status”.

NOTE

If there is no text information to display,
then “NO TITLE” is displayed.

Displayed genre name in equipment by type
(vehicles with a Bluetooth

2.0 interface).

The genre name display may not be possible.

During Bluetooth

2.0 Audio

Playback*

E00739000013

Operating details are the same as in “During
iPod Playback” (P.7-67).

Audio Quality and Volume
Balance Adjustment

E00738201246

Change audio quality settings.

Adjust Audio Quality and Vol-

ume Balance

1. Press the

/SEL key to select settings

items.

Each time the

/SEL key is pressed,

this switches in the order BASS, TRE-
BLE, FADER, BALANCE, SCV (speed
compensated volume), and Cancel.

2. Turn the /SEL key to adjust.

Adjust-

ment

items

Turn counter-

clockwise

Turn clockwise

BASS -6 to 0

(Decrease low
frequency vol-
ume)

0 to +6
(Increase low
frequency vol-
ume)

TRE-

BLE

-6 to 0
(Decrease high
frequency vol-
ume)

0 to +6
(Increase high
frequency vol-
ume)

FADER CENTER to

REAR 11
(emphasise
REAR)

FRONT 11 to
CENTER
(emphasise
FRONT)

Audio Quality and Volume Balance Adjustment

7-67

OKTE18E1

For pleasant driving

Adjust-

ment

items

Turn counter-

clockwise

Turn clockwise

BAL-

ANCE

LEFT 11 to
CENTER
(emphasise
LEFT)

CENTER to
RIGHT 11
(emphasise
RIGHT)

SCV

OFF, LOW
(SCV effect is
OFF/low)

MID, HIGH
(SCV effect is
middle/high)

System Settings

E00738301322

Change system settings such as product time.

1. Press the MENU key.
2. Press the

/SEL key to select settings

items.

Each time the

/SEL key is pressed,

this switches in the order DAB setting

Gracenote DB

, AF, REG, TP-S, PI-S,

PTY language settings, PHONE settings,
CT Adjust time, and Cancel.

3. Turn the /SEL key to set.

Displayed when a DAB tuner is connected.

Displayed when playing back audio files

(vehicles with a Bluetooth

2.0 interface).

4. Press the /SEL key to determine.

This completes settings, and displays the
next settings item.

DAB Setting*

Change DAB settings

(“Set value” bold typeface indicates factory
default settings.)

Settings

name

Settings val-

Settings con-

tent

DAB-DAB

Link settings

OFF

If low recep-
tion sensitivi-
ty, switch to
another serv-
ice.

DAB Band

settings

BAND III

Set used
broadcast
band to 174
to 239 MHz.

L-BAND

Set used
broadcast
band to 1452
to 1490 MHz.

Settings

name

Settings val-

Settings con-

tent

BOTH

Set used
broadcast
band to Band
III and L-
Band.

RDS Setting

Change RDS settings

(“Set value” bold typeface indicates factory
default settings.)

Settings

name

Settings val-

Settings con-

tent

AF ON

Automatical-
ly track the
same station
as the pro-
gram being
received.

AF OFF

Do not auto-
matically
track the
same station
as the pro-
gram being
received.

System Settings

7-68

OKTE18E1

For pleasant driving

Settings

name

Settings val-

Settings con-

tent

REG

REG ON

Do not auto-
matically
track the lo-
cal station for
the program
being re-
ceived.

REG OFF Automatical-

ly track the
local station
for the pro-
gram being
received.

TP-S

TP-S ON

Automatical-
ly search for
traffic mes-
sages (TP sta-
tions).

TP-S OFF Do not auto-

matically
search for
traffic mes-
sages (TP sta-
tions).

Settings

name

Settings val-

Settings con-

tent

PI-S

PI-S ON

Search for the
same station
or local sta-
tion for that
registered in
the preset
channel.

PI-S OFF

Do not search
for the same
station or lo-
cal station for
that regis-
tered in the
preset chan-
nel.

PTY

ENGLISH Set the dis-

play language
for the pro-
gram content
search (PTY
search) to
English.

Settings

name

Settings val-

Settings con-

tent

FRANCAIS Set the dis-

play language
for the pro-
gram content
search (PTY
search) to
French.

DEUTSCH Set the dis-

play language
for the pro-
gram content
search (PTY
search) to
German.

SVENSK

Set the dis-
play language
for the pro-
gram content
search (PTY
search) to
Swedish.

PTY

ESPANOL Set the dis-

play language
for the pro-
gram content
search (PTY
search) to
Spanish.

System Settings

7-69

OKTE18E1

For pleasant driving

Settings

name

Settings val-

Settings con-

tent

ITALIANO Set the dis-

play language
for the pro-
gram content
search (PTY
search) to
Italian.

CT ON

Update the
time if time
data is re-
ceived.

CT OFF

Do not up-
date the time
even if time
data is re-
ceived.

*: It is necessary to press the [TP] key and

turn traffic message standby mode
“ON”.

Time Setting

Turning the RDS setting CT setting “CT
OFF” enables manual setting of the time.

1. Select “YES” at the “Adjust time”

screen, and press the /SEL key.

The hour can be adjusted. Press the

/SEL key again to adjust the minutes.

2. Turn the /SEL key to adjust the time.
3. Press the /SEL key.

This completes the adjustment.

NOTE

In order to finish adjusting the time, hold
down the

/SEL key until the seconds are

reset to “00”.

PHONE Settings

Change the mobile phone voice cut-in set-
tings and the Bluetooth

2.0 interface lan-

guage.
Depending on the vehicle, PHONE settings
may not be possible.

NOTE

Cancel functions such as the mobile phone
“dial lock”, and connect while on the stand-
by screen.

While connected, mobile phone (receiving
calls, etc.) operations may not function cor-
rectly.

NOTE

Depending  on  the  distance  between  the
product  and  the  mobile  phone,  the  condi-
tions within the vehicle, and types of screen-
ing, connection may not be possible. In these
cases,  situate  the  mobile  phone  as  close  as
possible to the product.

Even though a Bluetooth-capable mobile
phone, characteristics and specifications
may mean that correct operation may not be
possible.

For safety’s sake, do not operate the mobile
phone while driving. When operating the
mobile phone, first stop the vehicle in a safe
location.

Even  though  a  Bluetooth-capable  mobile
phone,  phone  specifications  and  settings
may  result  in  differences  in  display,  or  pre-
vent correct operation.

Some models may not be confirmed as con-
nected, or may not connect.

Supported profiles

Hands-free

HFP(v1.5)

Phone book trans-

fer

OPP(v1.1),
PBAP(v1.0)

Vehicles without a Bluetooth

2.0 Interface

A hands-free kit (available separately) is re-
quired.

System Settings

7-70

OKTE18E1

For pleasant driving

(“Set value” bold typeface indicates factory
default settings.)

Settings

value

Settings content

PHONE

OFF

Do not use mobile phone voice
cut-in.

PHONE

MUTE

During mobile phone voice
cut-in, mute the audio.

PHONE

ATT

During mobile phone voice
cut-in, output audio from all
speakers.

PHONE

IN-L

During mobile phone voice
cut-in, output sound from the
left front speaker.

PHONE

IN-R

During mobile phone voice
cut-in, output sound from the
right front speaker.

PHONE

IN-LR

During mobile phone voice
cut-in, output sound from the
left and right front speakers.

Vehicles with a Bluetooth

2.0

Interface

(“Set value” bold typeface indicates factory
default settings.)

Settings name

Settings

value

Settings con-

tent

PHONE IN set-

tings

PHONE

IN-R

During mobile
phone voice
cut-in, output
sound from the
right front
speaker.

PHONE

IN-L

During mobile
phone voice
cut-in, output
sound from the
left front
speaker.

HFM voice lan-

guage settings

ENG-

LISH

Change the
hands free mod-
ule voice lan-
guage.

FRENCH

GER-
MAN

SPANISH

ITALIAN

DUTCH

HFM voice lan-

guage settings

PORTU-

GUESE

Change the
hands free mod-
ule voice lan-
guage.

RUSSI-

NOTE

Depending on the vehicle model, this may
not display.

Gracenote DB (Vehicles with a
Bluetooth

2.0 interface)

The version number can be confirmed.

1. Select “Gracenote DB” and press the

/SEL key.

2. Turn the

/SEL key and select “DB

Version”.

3. Press the /SEL key.

The DB Version is displayed.

System Settings

7-71

OKTE18E1

For pleasant driving

Mitsubishi L200 (2018 year). Instruction - part 17
