Mitsubishi ASX (2018 year). Instruction - part 10

Other interrupt displays

E00524202413

Screen type 1

Screen type 2

System operation status

Reference

––

When starting the engine, you
pressed the engine switch
without depressing the clutch
pedal (M/T).

On  vehicles  with  M/T,  place
the  gearshift  lever  in  the  “N”
(Neutral)  position,  fully  de-
press the clutch pedal, depress
the brake pedal with the right
foot.  Then,  press  the  engine
switch. Refer to “Starting and
stopping  the  engine”  on  page
3-17.

––

When starting the engine, the
selector  lever  is  in  a  position
other  than  the  “P”  (Park)  or
the “N” (Neutral) position, or
you pressed the engine switch
without  depressing  the  brake
pedal (A/T or CVT).

On  vehicles  with  A/T  or
CVT,  place  the  selector  lever
in  the  “P”  (PARK)  position,
depress  the  brake  pedal  with
the right foot. Then, press the
engine  switch.  Refer  to
“Starting and stopping the en-
gine” on page 3-17.

The operation status of each system is displayed on the information screen. Refer to the appropriate page for the system for further details.

NOTE

When operating each system, confirm that the operation status of the system has changed on the information screen. However, the operation status of the
system may not be displayed immediately after the warning display appears even if the system is operated.

Indication lamp, warning lamp, and information screen display list

5-42

OGAE18E1

Instruments and controls

Screen type 1

Screen type 2

System operation status

Reference

When “2WD” mode is selec-
ted with the drive mode selec-
tor

Refer to “Electronically con-
trolled 4WD system” on page
6-39.

When “4WD AUTO” mode is
selected with the drive mode
selector

When “4WD LOCK” mode is
selected with the drive mode
selector

When the Active Stability
Control (ASC) is operating

Refer to “Active Stability
Control (ASC)” on page
6-51.

Indication lamp, warning lamp, and information screen display list

5-43

OGAE18E1

Instruments and controls

Screen type 1

Screen type 2

System operation status

Reference

—

When  the  Forward  Collision
Mitigation  system  (FCM)  is
activated  or  the  timing  of  an
alarm is changed.

Refer to “FCM ON/OFF switch”
on page 6-63.

—

When the Forward Collision
Mitigation system (FCM) is
deactivated.

Refer to “FCM ON/OFF switch”
on page 6-63.

This informs you that a periodic inspection is due.

Screen type 1

Screen type 2

Solution

We recommend you to have it checked. Refer to “Service remind-
er” on page 5-16 for further details.

Indication lamp, warning lamp, and information screen display list

5-44

OGAE18E1

Instruments and controls

The setting for rest interval can be changed.

Screen type 1

Screen type 2

Solution

Stop the vehicle in a safe place, turn off the engine, and take a rest.
Use this display as rough guide for taking rests during a long drive.
The interval from the start of your trip until this message is displayed
can be set.
Refer to “Changing the function settings (when the ignition switch or
the operation mode is ON)” on page 5-19.
The display and buzzer alert the driver when the set time is reached. If
you continue to drive without having a rest, the buzzer sounds about
every 5 minutes to encourage you to take a rest.

In the following cases, the time driven is reset and the display re-
turns to the previous display screen. After this, when the set time
is reached again, the buzzer and display encourage you to take a
rest.

• The buzzer sounds 3 times.
• Turn the ignition switch to the “LOCK” position or put the op-

eration mode in OFF.

• The multi-information meter switch is held for about 2 seconds

or more.

Indication lamp, warning lamp, and information screen display list

5-45

OGAE18E1

Instruments and controls

Indication lamps

E00501600100

Turn-signal indication lamps/

Hazard warning indication

lamps

E00501700361

These indication lamps blink
in the following situations.

• When the turn-signal

lever  is  moved  to  ac-
tivate  a  turn-signal
lamp.
Refer  to  “Turn-signal
lever” on page 5-57.

• When the hazard

warning

flasher

switch  is  pressed  to
activate  the  hazard
warning lamps.
Refer  to  “Hazard
warning

• When the hazard

warning  lamps  auto-
matically activate due
to  sudden  braking
while driving.
Refer  to  “Emergency
stop  signal  system*”
on page 6-48.

NOTE

If these indication lamps blink too fast due
to any operation other than sudden braking,
the cause may be a blown lamp bulb or a
faulty turn-signal connection.

High-beam indication lamp

E00501800173

This indication lamp illumi-
nates when the high-beam is
used.

Front fog lamp indication

lamp*

E00501900350

This lamp illuminates while
the front fog lamps are on.

Rear fog lamp indication lamp

E00502001326

This lamp illuminates while
the rear fog lamp is on.

Position lamp indication lamp

E00508900173

This indication lamp illumi-
nates while the position
lamps are on.

Diesel preheat indication lamp

(diesel-powered vehicles)

E00502300247

This indicates the glow plug
preheat condition.
[Except  for  vehicles  equip-
ped  with  keyless  operation
system]
When  the  ignition  switch  is

turned to the “ON” position, the lamp illumi-
nates.  As  the  glow  plug  becomes  hot,  the
lamp goes out and the engine can be started.
[For  vehicles  equipped  with  keyless  opera-
tion system]
When  the  operation  mode  is  put  in  ON,  the
lamp  illuminates  and  preheating  of  the  glow
lamp  starts  automatically.  As  the  glow  plug
becomes  hot,  the  lamp  goes  out  and  the  en-
gine starts.

NOTE

If the engine is cold, the diesel preheat indi-
cation lamp is on for a longer time.

Indication lamps

5-46

OGAE18E1

Instruments and controls

NOTE

When the engine is warm, the diesel preheat
indication lamp does not come on even if the
ignition switch is turned to the “ON” posi-
tion or the operation mode is put in ON.

Warning lamps

E00502400147

Brake warning lamp

E00502502357

This  lamp  illuminates  when
the  ignition  switch  is  turned
to  the  “ON”  position  or  the
operation mode is put in ON,
and goes off after a few sec-
onds.

Always make sure that the lamp goes off be-
fore driving.
With the ignition switch or the operation
mode in ON, the brake warning lamp illumi-
nates under the following conditions:

When the parking brake lever has been
engaged.

When the brake fluid level in the reser-
voir falls to a low level.

When the brake force distribution func-
tion is not operating correctly.

CAUTION

In the situations listed below, brake perform-
ance  may  be  compromised  or  the  vehicle
may  become  unstable  if  brakes  are  applied
suddenly;  consequently,  avoid  driving  at
high speeds or applying the brakes suddenly.
Furthermore,  the  vehicle  should  be  brought
to  a  stop  in  a  safe  location  and  to  have  it
checked.

•

The brake warning lamp does not illumi-
nate when the parking brake is applied or
does not turn off when the parking brake
is released.

•

The ABS warning lamp and brake warn-
ing lamp illuminate at the same time
For details, refer to “ABS warning lamp”
on page 6-49.

•

The brake warning lamp remains illumi-
nated during driving.

The vehicle should be brought to a halt in
the following manner when brake perform-
ance has deteriorated.

•

Depress the brake pedal harder than usual.
Even if the brake pedal moves down to
the very end of its possible stroke, keep it
pressed down hard.

•

Should the brakes fail, use engine braking
to reduce your speed and pull the parking
brake lever.
Depress the brake pedal to operate the
stop lamp to alert the vehicles behind you.

Check engine warning lamp

E00502601960

This lamp is a part of an on-
board  diagnostic  system
which  monitors  the  emis-
sions,  engine  control  system
or  A/T  control  system/CVT
control system.

If a problem is detected in one of these sys-
tems, this lamp illuminates or flashes.
Although your vehicle will usually be driva-
ble and not need towing, we recommend you
to have the system checked as soon as possi-
ble.
This lamp will also illuminate when the igni-
tion switch is turned “ON” or the operation
mode is put in ON, and goes off after the en-
gine has started. If it does not go off after the
engine has started, we recommend you to
have the vehicle checked.

CAUTION

Prolonged driving with this lamp on may
cause further damage to the emission control
system. It could also affect fuel economy
and drivability.

If the lamp does not illuminate when the ig-
nition switch is turned to the “ON” position
or the operation mode is put in ON, we rec-
ommend you to have the system checked.

Warning lamps

5-47

OGAE18E1

Instruments and controls

CAUTION

If the lamp illuminates while the engine is
running, avoid driving at high speeds and
have

the

system

inspected

MITSUBISHI  MOTORS  Authorized  Serv-
ice Point as soon as possible.
Accelerator  pedal  and  brake  pedal  response
may  be  negatively  influenced  under  these
conditions.

NOTE

The engine electronic control module ac-
commodating the onboard diagnostic system
has various fault data (especially about the
exhaust emission) stored.

Charge warning lamp

E00502701192

This  lamp  illuminates  when
the  ignition  switch  is  turned
“ON” or the operation mode
is put in ON, and goes off af-
ter the engine has started.
A  warning  is  also  displayed

on the multi-information display.

CAUTION

If it illuminates while the engine is running,
there  is  a  problem  in  the  charging  system.
Immediately  park  your  vehicle  in  a  safe
place  and  we  recommend  you  to  have  it
checked.

Information screen display

E00524600051

Fuel filter indicator display*

E00529400083

Type 1

Type 2

When  the  ignition  switch  is  turned  to  the
“ON” position or the operation mode is put in
ON, if more water than the specified limit has
accumulated  in  the  fuel  filter,  the  warning
display  is  displayed  on  the  information
screen in the multi-information display.

CAUTION

If this warning display is displayed we rec-
ommend you to have it checked.
Prolonged driving with the warning display
shown may damage the engine.

NOTE

If  “REMOVE  WATER  IN  SEPARATOR”
does  not  go  out  or  appears  frequently  after
removing  the  water,  we  recommend  you  to
consult  a  MITSUBISHI  MOTORS  Author-
ized Service Point.

Brake warning display

E00524700267

Type 1

Type 2

Information screen display

5-48

OGAE18E1

Instruments and controls

This  warning  is  displayed  if  you  drive  with
the  parking  brake  still  applied.  The  warning
lamp  in  the  instrument  cluster  only  illumi-
nates when the parking brake is applied.

CAUTION

If a vehicle is driven without releasing the
parking brake, the brake will be overheated,
resulting in ineffective braking and possible
brake failure.
If this warning is displayed, release the park-
ing brake.

Type 1

Type 2

When the ignition switch is turned to the
“ON” position or the operation mode is put in
ON, if the brake fluid is low, this warning is
displayed.

The warning lamp in the instrument cluster
also illuminates.

CAUTION

If this warning stays illuminated and does
not go out while driving, there is a danger of
ineffective braking. In this case, immediate-
ly park your vehicle in a safe place and we
recommend you to have it checked.

If the brake warning display is displayed and
the brake warning lamp and the ABS warn-
ing  lamp  are  illuminated  at  the  same  time,
the  braking  force  distribution  function  will
not  operate,  so  the  vehicle  may  be  destabi-
lised  during  sudden  braking.  Avoid  sudden
braking and high-speed driving, stop the ve-
hicle in a safe place, and we recommend you
to have it checked.

The vehicle should be brought to a halt in
the following manner when brake perform-
ance has deteriorated.

•

Depress the brake pedal harder than usual.
Even if the brake pedal moves down to
the very end of its possible stroke, keep it
pressed down hard.

•

Should the brakes fail, use engine braking
to reduce your speed and pull the parking
brake lever.
Depress the brake pedal to operate the
stop lamp to alert the vehicles behind you.

Charge warning display

E00524800200

Type 1

Type 2

If  there  is  a  fault  with  the  charging  system,
the warning display is displayed on the infor-
mation  screen  in  the  multi-information  dis-
play.  The  warning  lamp  in  the  instrument
cluster also illuminates.

CAUTION

If the warning is displayed while the engine
is running, immediately park your vehicle in
a safe place and we recommend you to have
it checked.

Information screen display

5-49

OGAE18E1

Instruments and controls

Oil pressure warning display

E00524900214

Type 1

Type 2

If the engine oil pressure drops while the en-
gine is running, the warning display is dis-
played on the information screen in the multi-
information display.

CAUTION

If  the  vehicle  is  driven  while  the  engine  oil
is  low,  or  the  oil  level  is  normal  but  the
warning  is  displayed,  the  engine  may  burn
out and be damaged.

If the warning is displayed while the engine
is running, immediately park your vehicle in
a safe place and check the engine oil level.

If the warning is displayed while the engine
oil level is normal, have it inspected.

Engine oil level warning dis-

play*

E00526700072

Type 1

Type 2

When the ignition switch or the operation
mode is in ON, if it is suspected that the en-
gine oil level has increased excessively, the
warning display is displayed on the informa-
tion screen in the multi-information display.

CAUTION

If this warning is displayed while driving,
stop the vehicle in a safe place, turn off the
engine, and check the engine oil level.
Refer to “Engine oil” on page 10-05.

NOTE

Immediately have your vehicle checked by a
MITSUBISHI MOTORS Authorized Serv-
ice Point.

Combination headlamps
and dipper switch

E00506004543

Headlamps

NOTE

When  entering  a  country  in  which  vehicles
are driven on the opposite side of the road to
the  country  in  which  your  vehicles  is  sup-
plied,  necessary  measures  have  to  be  taken
to avoid dazzling oncoming traffic. Howev-
er,  headlamps  on  this  vehicle  do  not  need
any adjustment.

Do not leave the lights on for a long time
while the engine is stationary (not running).
A rundown battery could result.

When it rains, or when the vehicle has been
washed, the inside of the lens sometimes be-
comes foggy, but this does not indicate a
functional problem.
When the lamp is switched on, the heat will
remove the fog. However, if water gathers
inside the lamp, we recommend you to have
it checked.

Combination headlamps and dipper switch

5-50

OGAE18E1

Instruments and controls

NOTE

The bulbs of the high intensity discharge
headlamps (if so equipped) have the follow-
ing characteristics.

•

While the headlamps are used, the light
will gradually become a bluish-white col-
our.

•

The life time of a bulb becomes shorter as
it is repeatedly turned on and off.
When the bulb approaches the end of its
life time, the brightness may decrease, the
bulb may flicker, and the light may be-
come a reddish colour.

If this occurs, have the vehicle inspected at a
MITSUBISHI MOTORS Authorized Serv-
ice Point.

Type 1

Rotate the switch to turn on the lamps.

OFF All lamps off

Position, tail, licence plate and instru-
ment panel lamps on

Headlamps and other lamps go on

For information regarding the lighting condi-
tion of the daytime running lamps (if so
equipped), refer to “Daytime running
lamps*” on page 5-53.

Type 2

Rotate the switch to turn on the lamps.

OFF

All lamps off

AUTO

With the ignition switch or
the operation mode is in
ON, headlamps, position,
tail, licence plate, and in-
strument panel lamps turn
on and off automatically in
accordance with outside
light level. All lamps turn
off automatically when the
ignition switch is turned to
“LOCK” position or the op-
eration mode is put in OFF.

Position, tail, licence plate
and instrument panel lamps
on

Combination headlamps and dipper switch

5-51

OGAE18E1

Instruments and controls

Headlamps and other lamps
go on

For information regarding the lighting condi-
tion of the daytime running lamps (if so
equipped), refer to “Daytime running
lamps*” on page 5-53.

NOTE

On  vehicles  with  the  rain  sensor,  the  sensi-
tivity of the automatic on/off control can be
adjusted.  For  further  information,  contact  a
MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.

When  the  headlamps  are  turned  off  by  the
automatic  on/off  control  with  the  ignition
switch  in  the  “ON”  position,  the  front  fog
lamps (if so equipped) and rear fog lamps al-
so  go  off.  When  the  headlamps  are  subse-
quently  turned  back  on  by  the  automatic
on/off control, the front fog lamps also come
on  but  the  rear  fog  lamp  stays  off.  If  you
wish to turn the rear fog lamp back on, oper-
ate the switch again.

NOTE

Do not place anything on the automatic light
sensor (A), and do not clean with a glass
cleaner.

If  the  lamps  do  not  turn  on  or  off  with  the
switch  in  the  “AUTO”  position,  manually
operate  the  switch  and  we  recommend  you
to have your vehicle checked.

Lamps (headlamps, fog lamp,

etc.) auto-cutout function

If the following operation is performed
while the lamp switch is in the “

” po-

sition,  the  lamps  will  automatically  go
out when the driver’s door is opened.
[Except  vehicles  equipped  with  keyless
operation system]
The  ignition  switch  is  turned  to  the
“LOCK” or “ACC” position, or the key
is removed from the ignition switch.
[For vehicles equipped with keyless op-
eration system]

The operation mode is in OFF or ACC.

[When the engine was started using the
key]

• If the key is removed and the driver’s

door is opened, a buzzer sounds at a
high pitch intermittently to remind the
driver to turn off the lamps.

[When the engine was started using the
keyless operation function]

• If the operation mode is put in OFF

and the driver’s door is opened, a buz-
zer sounds at a high pitch intermittent-
ly to remind the driver to turn off the
lamps.

If the following operation is performed
while the lamp switch is in the “

” po-

sition,  the  lamps  will  remain  on  for
about  3  minutes  while  the  driver’s  door
is  shut  and  will  then  automatically  go
out.
[Except  vehicles  equipped  with  keyless
operation system]
The  ignition  switch  is  turned  to  the
“LOCK” or “ACC” position, or the key
is removed from the ignition switch.
[For vehicles equipped with keyless op-
eration system]
The operation mode is in OFF or ACC.

Combination headlamps and dipper switch

5-52

OGAE18E1

Instruments and controls

NOTE

The lamp auto-cutout will not function when
the lamp switch is in the “

” position.

The lamp auto-cutout function can also be
disabled.
For further information, we recommend you
to consult a MITSUBISHI MOTORS Au-
thorized Service Point.

When you want to keep the

lamps on:

1. In the following cases, turn the lamp

switch to the “OFF” position.
[Except vehicles equipped with keyless
operation system]
The ignition switch is in the “LOCK” or
“ACC” position.
[For vehicles equipped with keyless op-
eration system]
The operation mode is in OFF or ACC.

2. Turn on the lamps with the switch in the

“”

or “”

position again, then the

lamps will remain on.

NOTE

When the engine was started using the key,
if the driver’s door is opened and the key is
removed, the lamp monitor buzzer sounds at
a high pitch intermittently.

NOTE

The buzzer stops when the driver’s door is
closed. (The warning is also displayed on the
multi-information display.)
The buzzer stops in the following manner.

•

Turn the lamp switch to the “OFF” posi-
tion.

•

Close the driver’s door.

When the engine was started using the key-
less operation function, if the driver’s door is
opened  and  the  operation  mode  is  put  in
OFF,  the  lamp  monitor  buzzer  sounds  at  a
high pitch intermittently.
The  buzzer  stops  when  the  driver’s  door  is
closed. (The warning is also displayed on the
multi-information display.)
The buzzer stops in the following manner.

•

Turn the lamp switch to the “OFF” posi-
tion.

•

Close the driver’s door.

Lamp monitor buzzer

E00506100559

[When the engine was started using the key]
If the driver’s door is opened when the key is
in the “LOCK” or “ACC” position or re-
moved from the ignition switch while the
lamps are on, a buzzer will sound to remind
the driver to turn off the lamps.

[When the engine was started using the key-
less operation function]

If the driver’s door is opened when the opera-
tion mode is in ACC or OFF with the lamps
illuminated,  a  buzzer  will  sound  to  remind
the driver to turn off the lamps.

In  both  cases,  the  buzzer  will  automatically
stop  if  the  auto-cutoff  function  is  activated,
the  lamp  switch  is  turned  off,  or  the  door  is
closed.

Daytime running lamps*

E00530601529

The daytime running lamps come on when
the engine is running and the lamp switch is
in the “OFF” or “AUTO” position and the
tail lamps are off.

NOTE

If the lamp switch is in the “

” or “

”

position, or if the tail lamps are on when the
lamp switch is in the “AUTO” position, the
daytime running lamps come on as position
lamps.

Combination headlamps and dipper switch

5-53

OGAE18E1

Instruments and controls

Dipper (High/Low beam

change)

E00506200329

When the lamp switch is in the “

” posi-

tion, the beam changes from high to low (or
low  to  high)  each  time  the  lever  is  pulled
fully  (1).  While  the  high-beam  is  on,  the
high-beam  indication  lamp  in  the  instrument
cluster will also illuminate.

Headlamp flasher

E00506300199

The high-beams flash when the lever is
pulled slightly (2), and will go off when it is
released.
When the high-beam is on, the high-beam in-
dication lamp in the instrument cluster will il-
luminate.

NOTE

The high-beams can also flash when the
lamp switch is OFF.

If you turn the lamps off with the headlamps
set to high-beam, the headlamps are auto-
matically returned to their low-beam setting
when the lamp switch is next turned to the
“

” position.

Welcome light*

E00528902069

This  function  turns  on  the  position  and  tail
lamps  for  about  30  seconds  after  the  UN-
LOCK  switch  (A)  on  the  remote  control
transmitter  is  pressed  when  the  combination
headlamps and dipper switch is in the “OFF”
or  “AUTO”  position  (for  vehicles  equipped
with the automatic lamp control). On vehicles
equipped  with  automatic  lamp  control,  the
welcome  light  function  will  operate  only
when it is dark outside the vehicle.

NOTE

While the welcome light function is operat-
ing, perform one of the following operations
to cancel the function.

•

Push the LOCK switch (B) on the remote
control transmitter.

•

Turn the combination headlamps and dip-
per switch to the “

” or “

” position.

•

Turn the ignition switch to the “ON” posi-
tion or put the operation mode in ON.

It is possible to modify functions as follows:

•

The headlamps can be set to come on in
the low beam setting.

•

The welcome light function can be deacti-
vated.

For further information, please contact your
MITSUBISHI MOTORS Authorized Serv-
ice Point.

Combination headlamps and dipper switch

5-54

OGAE18E1

Instruments and controls

Coming home light

E00529001709

This  function  turns  on  the  headlamps  in  the
low  beam  setting  for  about  30  seconds  after
the  ignition  switch  is  turned  to  the  “LOCK”
position or the operation mode is put in OFF.

1. Turn the combination headlamps and

dipper switch to the “OFF” or “AUTO”
position (for vehicles equipped with the
automatic lamp control).

2. Turn the ignition switch to the “LOCK”

position or put the operation mode in
OFF. Also, if a key was used to start the
engine, remove the key from the ignition
switch.

3. Within 60 seconds of turning the igni-

tion switch to the “OFF” position or put-
ting the operation mode in OFF, pull the
turn signal lever towards you.

4. The headlamps will come on in the low

beam setting for about 30 seconds. After
the headlamps go off, the headlamps can
be turned on again in the low beam set-
ting for about 30 seconds by pulling the
turn  signal  lever  towards  you  within  60
seconds of turning the ignition switch to
the  “LOCK”  position  or  putting  the  op-
eration mode in OFF.
To turn on the headlamps again after 60
seconds of turning the ignition switch to
the  “LOCK”  position  or  putting  the  op-
eration mode in OFF, repeat the process
from step 1.

NOTE

While the coming home light function is op-
erating, perform one of the following opera-
tions to cancel the function.

•

Pull the lever towards you.

•

Turn the combination headlamps and dip-
per switch to the “

” or “

” position.

•

Turn the ignition switch to the “ON” posi-
tion or put the operation mode in ON.

It is possible to modify functions as follows:

•

The time that the headlamps remain on
can be changed.

•

The coming home light function can be
deactivated.

For further information, please contact your
MITSUBISHI MOTORS Authorized Serv-
ice Point.

Headlamp levelling

E00517400031

Headlamp levelling switch (ex-

cept for vehicles with discharge

headlamps)

E00517501677

The  angle  of  the  headlamp  beam  varies  de-
pending on the load carried by the vehicle.
The headlamp levelling switch can be used to
adjust  the  headlamp  illumination  distance
(when the lower beam is illuminated) so that
the  headlamps’  glare  does  not  distract  other
drivers.
Set the switch according to the following ta-
ble.

Headlamp levelling

5-55

OGAE18E1

Instruments and controls

CAUTION

Always perform adjustments before driving.
Do not attempt to adjust while driving, as it
could cause an accident.

Vehicle condition

Switch position

“0”

“1”

“2”

“3”

●:1 person

:Full luggage loading

Switch position
0-

Driver only/Driver + 1
front passenger

Switch position
1-

5 passengers (including
driver)

Switch position
2-

5 passengers (including
driver) + Full luggage
loading

Switch position
3-

Driver + Full luggage
loading

Automatic headlamp levelling

(vehicles with discharge head-

lamps)

E00517600453

This mechanism automatically adjusts the di-
rection of the headlamps (beam position) de-
pending  on  changes  in  the  condition  of  the
vehicle,  such  as  the  number  of  occupants  or
luggage  weight.  When  the  headlamps  are  il-
luminated with the ignition switch or the op-
eration mode in ON, the beam position of the
headlamps is automatically adjusted when the
vehicle is stopped.

Headlamp automatic levelling

system warning display

Type 1

Type 2

If there is a fault in the automatic headlamp
levelling system, the warning display is dis-
played on the information screen in the multi-
information display.

CAUTION

If a warning is displayed, the system may be
malfunctioning, so we recommend you to
have your vehicle inspected.

Headlamp levelling

5-56

OGAE18E1

Instruments and controls

Turn-signal lever

E00506501592

1- Turn-signals

When making a normal turn, use posi-
tion (1). The lever will return automati-
cally when cornering is completed.

2- Lane-change signals

When moving the lever to (2) slightly to
change a lane, the turn-signal lamps and
indication lamp in the instrument cluster
will only flash while the lever is operat-
ed.
Also, when you move the lever to (2)
slightly then release it, the turn-signal
lamps and indication lamp in the instru-
ment cluster will flash 3 times.

NOTE

If the lamp flashes unusually quickly, the
bulb in a turn-signal lamp may have burned
out. We recommend you to have the vehicle
inspected.

It is possible to activate the following func-
tions.

•

Flashing of the turn-signal lamps when
the lever is operated with the ignition
switch or the operation mode is in ACC.

•

Deactivate the turn-signal lamp 3-flash
function for lane changes.

•

The time required to operate the lever for
the 3-flash function can be adjusted.

For further information, we recommend you
to consult a MITSUBISHI MOTORS Au-
thorized Service Point.

Hazard warning flasher
switch

E00506600860

Use the hazard warning flasher switch when
the vehicle has to be parked on the road for
any emergency.
The hazard warning flashers can always be
operated, regardless of the ignition switch po-
sition or the operation mode.

Push the switch to turn on the hazard warning
flashers, all turn-signal lamps flash continu-
ously. To turn them off, push the switch
again.

NOTE

While the hazard warning lamps are blinking
due  to  having  manually  pushed  the  switch,
the  emergency  stop  signal  system  does  not
operate.
Refer  to  “Emergency  stop  signal  system*”
on page 6-48.

Turn-signal lever

5-57

OGAE18E1

Instruments and controls

Content .. 8 9 10 11 ..
