Mitsubishi Outlander XL. Manual - part 146

IGNITION KEY REMINDER TONE ALARM <VEHICLES WITH KOS>

CIRCUIT DIAGRAMS

90-281

CAN DRIVE CIRCUIT

CPU

INTERFACE CIRCUIT

COMBINATION METER

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

ETACS-ECU

(FUSE    )

12

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

LCD

(KEY REMINDER)

TONE ALARM

DOOR AJAR WARNING TONE ALARM

CIRCUIT DIAGRAMS

90-282

DOOR AJAR WARNING TONE ALARM

ETACS-
ECU

POWER
DISTRIBUTION
SYSTEM

FUSIBLE
LINK

34

IGNITION
SWITCH (IG1)

IG1
RELAY

INTERFACE
CIRCUIT

CAN TRANSCEIVER
CIRCUIT

LCD

(EACH DOOR)

CPU

COMBINATION
METER

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

TONE ALARM

DOOR AJAR WARNING TONE ALARM

CIRCUIT DIAGRAMS

90-283

LIFTGATE
SWITCH

SECOND SEAT
ONE-TOUCH
TUMBLE
MECHANISM

REAR DOOR
SWITCH (RH)

REAR DOOR
SWITCH (LH)

FRONT DOOR
SWITCH (LH)

FRONT DOOR
SWITCH (RH)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

·AIR CONDITIONING SYSTEM
·BRAKE WARNING LIGHT
·CENTRAL DOOR LOCKING SYSTEM
·CONTROLLER AREA NETWORK (CAN)
·DAYTIME RUNNING LIGHT
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEADLIGHT AUTOMATIC LEVELING
 SYSTEM

·HEATED DOOR MIRROR
·HEATED SEAT
·IGNITION KEY REMINDER
 TONE ALARM
·IMMOBILIZER SYSTEM
·INVECS-II 6A/T
·KEYLESS OPERATING SYSTEM (KOS)
·POWER WINDOWS
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF

·SUPPLEMENTAL RESTRAINT SYSTEM
 (SRS)
·TAILLIGHT, POSITION LIGHT, LICENSE
 PLATE LIGHT AND LIGHTING MONITOR
 TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING SYSTEM
 (TPMS)
·TURN-SIGNAL LIGHT AND HAZARD
 WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

:

NOTE

DOOR AJAR WARNING TONE ALARM

CIRCUIT DIAGRAMS

90-284

DOOR AJAR WARNING TONE ALARM (CONTINUED)

ETACS-
ECU

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

FUSIBLE
LINK

34

TRANSMISSION
CONTROL
MODULE

INPUT SIGNAL

OUTPUT SHAFT
SPEED SENSOR

DATA LINK
CONNECTOR

FRONT SIDE
