Mitsubishi Outlander XL. Manual - part 127

REAR SEAT ENTERTAINMENT SYSTEM

CIRCUIT DIAGRAMS

90-205

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

DATA LINK
CONNECTOR

ETACS-
ECU

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

ETACS-ECU

(FUSE    )

5

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

REAR SEAT ENTERTAINMENT SYSTEM

CIRCUIT DIAGRAMS

90-206

REAR SEAT ENTERTAINMENT SYSTEM (CONTINUED)

AUDIO VISUAL NAVIGATION UNIT

REAR DISPLAY UNIT

REAR SEAT ENTERTAINMENT SYSTEM

CIRCUIT DIAGRAMS

90-207

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

AUDIO AND VIDEO ADAPTER

VIDEO IN

AUDIO
R

AUDIO
L (MONO)

REAR SEAT ENTERTAINMENT SYSTEM

CIRCUIT DIAGRAMS

90-208

REAR SEAT ENTERTAINMENT SYSTEM (CONTINUED)

TWEETER

FRONT DOOR SPEAKER

(LH)

(RH)

(LH)

(RH)

<VEHICLES WITHOUT AUDIO AMPLIFIER>

AUDIO VISUAL NAVIGATION UNIT
