REMOTE CONTROLLED MIRROR

CIRCUIT DIAGRAMS

90-165

DOOR MIRROR ASSEMBLY (LH)

VERTICAL
MOVEMENT
MOTOR

HORIZONTAL
MOVEMENT
MOTOR

DOOR MIRROR ASSEMBLY (RH)

VERTICAL
MOVEMENT
MOTOR

HORIZONTAL
MOVEMENT
MOTOR

REMOTE CONTROLLED
MIRROR SWITCH

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

AUDIO SYSTEM <VEHICLES WITHOUT AUDIO AMPLIFIER>

CIRCUIT DIAGRAMS

90-166

AUDIO SYSTEM

<VEHICLES WITHOUT AUDIO AMPLIFIER>

FUSIBLE
LINK

34

FUSIBLE
LINK

36

POWER
DISTRIBUTION
SYSTEM

CENTER PANEL UNIT

ETACS-
ECU

AUDIO SWITCH PANEL

LCD PANEL (AUDIO)

RADIO AND CD PLAYER OR CD CHANGER

RELAY BOX

ENGINE
COMPARTMENT

THEFT-ALARM
SYSTEM

HANDS FREE
SYSTEM

AUDIO SYSTEM <VEHICLES WITHOUT AUDIO AMPLIFIER>

CIRCUIT DIAGRAMS

90-167

FUSIBLE
LINK

37

ACC
RELAY 2

ROOF ANTENNA

ANTENNA
AMPLIFIER

ANTENNA FEEDER CABLE

ETACS-
ECU

IGNITION
SWITCH (ACC)

·HEATED DOOR
 MIRROR
·REAR WINDOW
 DEFOGGER

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

REMOTE
CONTROLLED
MIRROR

AUDIO SYSTEM <VEHICLES WITHOUT AUDIO AMPLIFIER>

CIRCUIT DIAGRAMS

90-168

AUDIO SYSTEM <VEHICLES WITHOUT AUDIO AMPLIFIER> (CONTINUED)

COMBINATION
METER

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

CPU

FRONT DOOR SPEAKER

TWEETER

ETACS-ECU

(FUSE    )

9

RHEOSTAT

TONE
ALARM

INTERFACE
CIRCUIT

(LH)

(RH)

(LH)

(RH)

RADIO AND CD PLAYER OR CD CHANGER
