GROUP 54Af

ALARM SYSTEM

CONTENTS

GENERAL INFORMATION...........

54Af-2

SPECIAL TOOLS.................

54Af-2

DIAGNOSIS



<THEFT ALARM>........

54Af-4

STANDARD FLOW OF DIAGNOSTIC
TROUBLESHOOTING...............

54Af-4

DIAGNOSTIC FUNCTION...........

54Af-4

TROUBLE SYMPTOM CHART.........

54Af-6

SYMPTOM PROCEDURES............

54Af-7

Inspection Procedure 1: The theft-
alarm is not armed (the theft-alarm
indicator does not illuminate).
...............................

.54Af-7

Inspection Procedure 2: The interior
alarm does not work normally while the
theft-alarm is triggered.......

54Af-13

Inspection Procedure 3: Theft-alarm
horn does not sound while the theft-
alarm system is triggered......

54Af-15

Inspection Procedure 4: Horns do not
sound while the theft-alarm system is
triggered......................

54Af-19

Inspection Procedure 5: Panic alarm
does not work normally.........

54Af-25

ON-VEHICLE SERVICE

 <THEFT ALARM>

.

54Af-27

CONFIGURATION FUNCTION.......

54Af-27

HORN.........................

54Af-28

REMOVAL AND INSTALLATION. . . . .

54Af-28

INSPECTION...................

54Af-29

HORN RELAY CHECK...............

54Af-29

THEFT ALARM..................

54Af-29

REMOVAL AND INSTALLATION. . . . .

54Af-29

INSPECTION...................

54Af-30

THEFT-ALARM INDICATOR CHECK....

54Af-30

PANIC ALARM SYSTEM...........

54Af-30

REMOVAL AND INSTALLATION. . . . .

54Af-30

54Af-1

GENERAL INFORMATION

M15410300001USA0000010000

｠

When the doors are locked using the keyless entry
or KOS (excluding locking using the key cylinder or
others),  the  improper  opening  of  door  or  hood
causes  the  ETACS-ECU  function  and  control  to
give off an alarm with the flashing of head lights and
the intermittent sounding of horn. Also, the ETACS-

ECU warns that the theft-alarm system is being set
by flashing the theft-alarm indicator.

｠

By  pressing  the  panic  button  of  transmitter,  the
flashing of head lights and the intermittent sounding
of  horn  can  be  performed  by  remote  control
operation.

CONSTRUCTION DIAGRAM

ZC6013810000

Hood latch
(incorporating hood switch)

Theft-alarm indicator

Horn (for theft-alarm)

ETACS-ECU

Headlight

Panic button

Horn (HI)

Horn (LO)

SPECIAL TOOLS

M15410300002USA0000010001

Tool

Tool  number  and
name

Supersession

Application

MB990784

MB990784
Ornament remover

General  service
tool

Removal  of  center  air  outlet,  center
panel.

54Af-2

ALARM SYSTEM

GENERAL INFORMATION

Tool

Tool  number  and
name

Supersession

Application

MB991910

MB991826

YB9919580000

MB991911

MB991914

MB991824

MB991827

MB991825

Do not use

Do not use

a

b

c

d

e

f

g

MB991958

a.

MB991824

b.

MB991827

c.

MB991910

d.

MB991911

e.

MB991914

f.

MB991825

g.

MB991826

M.U.T.-III

 sub

assembly

a.

Vehicle
communication
interface (V.C.I.)

b.

M.U.T.-III  USB
cable

c.

M.U.T.-III  main
harness

 A

(Vehicles

 with

CAN
communication
system)

d.

M.U.T.-III  main
harness

 B

(Vehicles
without

 CAN

communication
system)

e.

M.U.T.-III  main
harness  C  (for
Daimler Chrysler
models only)

f.

M.U.T.-III
measurement
adapter

g.

M.U.T.-III  trigger
harness

MB991824-KIT

NOTE:

G:

MB991826 M.U.T.-
III Trigger
Harness is not
necessary when
pushing V.C.I.
ENTER key.

M.U.T.-III

 main

 harness

 A

(MB991910)  should  be  used.
M.U.T.-III  main  harness  B  and  C
should not be used for this vehicle.
Reading diagnostic trouble code

ALARM SYSTEM

54Af-3

SPECIAL TOOLS

Tool

Tool  number  and
name

Supersession

Application

YB9912230000

Do not use

a

b

c

d

MB991223

a.

MB991219

b.

MB991220

c.

MB991221

d.

MB991222

Harness set

a.

Test harness

b.

LED harness

c.

LED

 harness

adaptor

d.

Probe

General  service
tool

Continuity

 check

 and

 voltage

measurement  at  harness  wire  or
connector.

a.

Connector  pin  contact  pressure
inspection

b.

Power circuit inspection

c.

Power circuit inspection

d.

Commercial tester connection

MB992006

MB992006
Extra fine probe

-

Continuity

 check

 and

 voltage

measurement  at  harness  wire  or
connector.

DIAGNOSIS

STANDARD FLOW OF DIAGNOSTIC TROUBLESHOOTING

M15410300028USA0000010002

Refer to GROUP 00 - Contents of troubleshooting P.
00-6.

DIAGNOSTIC FUNCTION

M15410300042USA0000010001

HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)

Required Special Tools:

｠

MB991958: Scan Tool (M.U.T.-III Sub Assembly)

｠

MB991824: Vehicle Communication Interface (V.C.I.)

｠

MB991827: M.U.T.-III USB Cable

｠

MB991910:  M.U.T.-III  Main  Harness  A  (Vehicles  with
CAN communication system)

54Af-4

ALARM SYSTEM

DIAGNOSIS
