HEADLIGHT <DISCHARGE TYPE>

CIRCUIT DIAGRAMS

90-73

CPU

CAN DRIVE CIRCUIT

INTERFACE CIRCUIT

COMBINATION
METER

CAN
TRANSCEIVER CIRCUIT

LED DRIVE CIRCUIT

BEAM

12

(FUSE     )

ETACS-ECU

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

TAILLIGHT, POSITION LIGHT, REAR SIDE MARKER LIGHT, LICENSE PLATE LIGHT AND LIGHTING MONITOR TONE ALARM

CIRCUIT DIAGRAMS

90-74

TAILLIGHT, POSITION LIGHT, REAR SIDE MARKER LIGHT,

LICENSE PLATE LIGHT AND LIGHTING MONITOR TONE ALARM

REAR
COMBINATION
LIGHT (LH)

FUSIBLE
LINK

34

ETACS-
ECU

TAILLIGHT
CONTROL CIRCUIT

REAR
COMBINATION
LIGHT (RH)

LICENSE
PLATE
LIGHT (RH)

LICENSE
PLATE
LIGHT (LH)

POWER
DISTRIBUTION
SYSTEM

TAILLIGHT, POSITION LIGHT, REAR SIDE MARKER LIGHT, LICENSE PLATE LIGHT AND LIGHTING MONITOR TONE ALARM

CIRCUIT DIAGRAMS

90-75

REAR SIDE
MARKER
LIGHT (RH)

REAR SIDE
MARKER
LIGHT (LH)

HEADLIGHT
ASSEMBLY
(LH)

HEADLIGHT
ASSEMBLY
(RH)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

TAILLIGHT, POSITION LIGHT, REAR SIDE MARKER LIGHT, LICENSE PLATE LIGHT AND LIGHTING MONITOR TONE ALARM

CIRCUIT DIAGRAMS

90-76

TAILLIGHT, POSITION LIGHT, REAR SIDE MARKER LIGHT, LICENSE PLATE LIGHT AND LIGHTING
MONITOR TONE ALARM (CONTINUED)

:

NOTE

:

FUSIBLE
LINK

34

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

WHEN
REMOVING
KEY:ON

FRONT
SIDE

KEY
REMINDER
SWITCH

DATA LINK
CONNECTOR

FRONT DOOR
SWITCH (LH)

ETACS-
ECU

·AIR CONDITIONING
 SYSTEM
·BRAKE WARNING LIGHT
·CENTRAL DOOR
 LOCKING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT
 AND IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FUEL WARNING LIGHT
·IGNITION KEY REMINDER
 TONE ALARM
·IMMOBILIZER SYSTEM

·KEYLESS OPERATING
 SYSTEM (KOS)
·METER AND GAUGE
·OIL PRESSURE
 WARNING LIGHT
·POWER WINDOWS
·SEAT BELT WARNING
 TONE ALARM
·SUNROOF
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
 MONITORING SYSTEM
 (TPMS)

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM
 (ABS)
·ANTI-LOCK BRAKING SYSTEM
 (ABS) AND ACTIVE SKID
 CONTROL SYSTEM (ASC)
·CENTRAL DOOR LOCKING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT
 AND IGNITION KEY HOLE
 ILLUMINATION LIGHT
·HEADLIGHT AUTOMATIC
 LEVELING SYSTEM

·HEATED DOOR MIRROR
·HEATED SEAT
·IMMOBILIZER SYSTEM
·INVECS-II 6A/T
·KEYLESS OPERATING SYSTEM (KOS)
·POWER WINDOWS
·REAR WINDOW DEFOGGER
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
 SYSTEM (SRS)
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
 MONITORING SYSTEM (TPMS)
