MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) <3.0L ENGINE> 13B-253 STEP 1. Check harness connector B-02 at the right bank YES : Go to Step 2. Inspection P.00E-2 . Then go to Step 4. STEP 2. Check for short circuit to power supply between YES : Go to Step 3. STEP 3. Check the trouble symptoms. Diagnostic Function − OBD-II Drive Cycle − Pattern 22 (2) Check the diagnostic trouble code (DTC). YES : Replace the ECM. When the ECM is replaced, register the ID code. Refer to GROUP 42B, Diagnosis with KOS> P.42B-15 or GROUP 42C, Diagnosis − ID Codes Registration Judgment Table <Vehicles with P.42C-10 . Then go to Step 4. NO : It can be assumed that this malfunction is intermittent. Refer to GROUP 00, How to Use − How to Cope with Intermittent Malfunctions P.00-15 . STEP 4. Test the OBD-II drive cycle. Diagnostic Function − OBD-II Drive Cycle − Pattern 22 (2) Check the diagnostic trouble code (DTC). YES : Retry the troubleshooting. |
