THEFT-ALARM SYSTEM <VEHICLES WITH THEFT-ALARM SENSOR>

TSB Revision

CIRCUIT DIAGRAMS

90-405

HOOD
LATCH
SWITCH

JOINT CONNECTOR
(CAN1)

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ETACS-ECU

(FUSE    )

8

CAN TRANSCEIVER
CIRCUIT

COMBINATION METER

CPU

TONE
ALARM

RHEOSTAT

ETACS-
ECU

LCD

THEFT-ALARM
INDICATOR

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

THEFT-ALARM SYSTEM <VEHICLES WITH THEFT-ALARM SENSOR>

TSB Revision

CIRCUIT DIAGRAMS

90-406

THEFT-ALARM SYSTEM <VEHICLES WITH THEFT-ALARM SENSOR> (CONTINUED)

FUSE

8

ETACS-
ECU

THEFT-
ALARM
SIREN

LIN
CUT OFF
CONTROL
UNIT

FRONT SIDE

ETACS-ECU

(FUSE    )

8

·DAYTIME RUNNING
 LIGHT (DRL)
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·POWER WINDOWS

·REAR WIPER AND WASHER
·TAILLIGHT, POSITION LIGHT,
 REAR SIDE MARKER LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR
 TONE ALARM

·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND
 WASHER

:

NOTE

THEFT-ALARM SYSTEM <VEHICLES WITH THEFT-ALARM SENSOR>

TSB Revision

CIRCUIT DIAGRAMS

90-407

CAN DRIVE
CIRCUIT

POWER
DISTRIBUTION
SYSTEM

INTERFACE
CIRCUIT

LIN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

DATA LINK
CONNECTOR

THEFT-ALARM
SENSOR

·HEADLIGHT
·TAILLIGHT,
 POSITION LIGHT,
 REAR SIDE MARKER
 LIGHT, LICENSE
 PLATE LIGHT AND
 LIGHTING MONITOR
 TONE ALARM
·WINDSHIELD
 WIPER AND WASHER

·HEADLIGHT
·SUNROOF
·TAILLIGHT, POSITION
 LIGHT, REAR SIDE
 MARKER LIGHT, LICENSE
 PLATE LIGHT AND
 LIGHTING MONITOR TONE
 ALARM
·WINDSHIELD WIPER AND
 WASHER

ETACS-ECU

(FUSE    )

8

FUSIBLE
LINK

34

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

THEFT-ALARM SYSTEM <VEHICLES WITH THEFT-ALARM SENSOR>

TSB Revision

CIRCUIT DIAGRAMS

90-408

THEFT-ALARM SYSTEM <VEHICLES WITH THEFT-ALARM SENSOR> (CONTINUED)

<VEHICLES WITHOUT KOS>

KEYLESS
ENTRY
RECEIVER

KEYLESS
ENTRY
TRANSMITTER

WIRELESS CONTROL MODULE

ID
CODE

ETACS-ECU

FUSIBLE
LINK

34

IGNITION
SWITCH (IG1)

HEADLIGHT
RELAY (HIGH)

HEADLIGHT
RELAY (LOW)

IG1
RELAY

FUSE

8

CAN DRIVE
CIRCUIT

JOINT CONNECTOR
(CAN1)

IMMOBILIZER
ANTENNA

TRANSPONDER

IGNITION
CONTROL
CIRCUIT

HEADLIGHT
BACKUP
CIRCUIT
