SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

TSB Revision

CIRCUIT DIAGRAMS

90-329

CPU

CPU

SRS-ECU

SIDE IMPACT SENSOR
(FRONT : RH)

SIDE IMPACT SENSOR
(REAR : RH)

NOTE

: CONNECTOR COUPLED : ON

CONNECTOR UNCOUPLED : OFF

SIDE-AIR BAG MODULE
(SQUIB) (RH)

CURTAIN AIR BAG MODULE
(SQUIB) (RH)

ACCELERO
METER

ACCELERO
METER

CONNECTOR
LOCK SWITCH

CONNECTOR
LOCK
SWITCH

CONNECTOR
LOCK
SWITCH

CONNECTOR
LOCK
SWITCH

CONNECTOR
LOCK SWITCH

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

TSB Revision

CIRCUIT DIAGRAMS

90-330

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) (CONTINUED)

ETACS-
ECU

POWER
DISTRIBUTION
SYSTEM

FUSIBLE
LINK

34

IGNITION
SWITCH (IG1)

IG1
RELAY

SRS-ECU

NOTE

:

POWER
SUPPLY

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING
 SYSTEM (ABS)
·ANTI-LOCK BRAKING
 SYSTEM (ABS) AND ACTIVE
 STABILITY CONTROL
 SYSTEM (ASC)
·CENTRAL DOOR LOCKING
 SYSTEM
·DAYTIME RUNNING LIGHT
 (DRL)
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT
 AND IGNITION KEY HOLE
 ILLUMINATION LIGHT

·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEATED DOOR MIRROR
·HEATED SEAT
·IGNITION KEY
 REMINDER TONE ALARM
 <VEHICLES WITH KOS>
·IMMOBILIZER SYSTEM
·INVECS-II 6A/T
·INVECS-III CVT
·KEYLESS OPERATING
 SYSTEM (KOS)
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER

·SHIFT LOCK MECHANISM
·SUNROOF
·TAILLIGHT, POSITION LIGHT,
 REAR SIDE MARKER LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR
 TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
 MONITORING SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND
 WASHER

·ELECTRONIC
 CONTROLLED
 AWD
·S-AWC

·ANTI-LOCK BRAKING
 SYSTEM (ABS)
 AND ACTIVE
 STABILITY CONTROL
 SYSTEM (ASC)
·BACKUP LIGHT
·INVECS-II 6A/T
·INVECS-III CVT
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·SPARE CONNECTOR
 (FOR NAVIGATION
 SYSTEM)
·SPARE CONNECTOR
 (FOR TRAILER LIGHTS)

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

TSB Revision

CIRCUIT DIAGRAMS

90-331

COMBINATION METER

LCD (SRS)

CPU

RHEOSTAT

FRONT SIDE

CAN DRIVE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

CAN
TRANSCEIVER
CIRCUIT

DATA LINK
CONNECTOR

ETACS-ECU

(FUSE    )

12

LED DRIVE
CIRCUIT

JOINT
CONNECTOR
(CAN1)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

TSB Revision

CIRCUIT DIAGRAMS

90-332

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) (CONTINUED)

(FUSE     )

17

ETACS-ECU

POWER
SUPPLY

OCCUPANT
CLASSIFICATION-
ECU

HALL IC

SEAT
SLIDE
SENSOR

·ELECTRONIC
 CONTROLLED AWD
·S-AWC

FRONT SEAT
ASSEMBLY (RH)

JOINT CONNECTOR
(CAN1)
