CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-181

FRONT DOOR
SWITCH (RH)

FRONT DOOR
SWITCH (LH)

REAR DOOR
SWITCH (LH)

REAR DOOR
SWITCH (RH)

LIFTGATE
SWITCH

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-182

CENTRAL DOOR LOCKING SYSTEM (CONTINUED)

FUSIBLE
LINK

36

RELAY BOX

ENGINE
COMPARTMENT

IGNITION
SWITCH (IG1)

FUSIBLE
LINK

34

IG1
RELAY

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

KEYLESS
ENTRY
RECEIVER

WIRELESS CONTROL MODULE

KEYLESS
ENTRY
TRANSMITTER

<VEHICLES
WITHOUT KOS>

CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-183

POWER SUPPLY

INPUT SIGNAL

LOCK/UNLOCK
SWITCH

KOS-ECU

KEYLESS
ENTRY
RECEIVER

KEYLESS
OPERATION
KEY

RECEIVER ANTENNA MODULE

JOINT
CONNECTOR
(CAN1)

NOTE

:

: ·AIR CONDITIONING SYSTEM

·AUDIO SYSTEM
·BRAKE WARNING LIGHT, FUEL
 WARNING LIGHT AND OIL PRESSURE
 WARNING LIGHT
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT,
 LUGGAGE COMPARTMENT
 LIGHT AND IGNITION KEY
 HOLE ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEADLIGHT MANUAL LEVELING SYSTEM
·IGNITION KEY REMINDER TONE ALARM
·KEYLESS OPERATING SYSTEM (KOS)
·METER AND GAUGE
·MITSUBISHI MULTI-COMMUNICATION
 SYSTEM (MMCS)
·REAR SEAT ENTERTAINMENT SYSTEM
·REAR WIPER AND WASHER
·SPARE CONNECTOR (FOR REAR DISPLAY)
·TAILLIGHT, POSITION LIGHT, REAR SIDE
 MARKER LIGHT, LICENSE PLATE LIGHT
 AND LIGHTING MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TURN-SIGNAL LIGHT AND HAZARD
 WARNING LIGHT
·UNIVERSAL SERIAL BUS (USB) BOX
·WINDSHIELD WIPER AND WASHER

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
·ANTI-LOCK BRAKING SYSTEM (ABS)
 AND ACTIVE STABILITY CONTROL
 SYSTEM (ASC)
·BRAKE WARNING LIGHT, FUEL
 WARNING LIGHT AND OIL PRESSURE
 WARNING LIGHT
·CHARGING SYSTEM
·COOLING SYSTEM
·CRUISE CONTROL SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOOR AJAR WARNING TONE ALARM
·ELECTRONIC CONTROLLED AWD
·FOG LIGHT
·GLOVE BOX LIGHT
·HANDS-FREE INTERFACE SYSTEM
·HEADLIGHT
·HEATED DOOR MIRROR
·HEATED SEAT
·INVECS-II 6A/T

·INVECS-III CVT
·METER AND GAUGE
·MFI SYSTEM
·PARKING BRAKE REMINDER TONE
 ALARM
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·S-AWC
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT SYSTEM
 (SRS)
·TAILLIGHT, POSITION LIGHT, REAR SIDE
 MARKER LIGHT, LICENSE PLATE LIGHT
 AND LIGHTING MONITOR TONE ALARM
·TIRE PRESSURE MONITORING SYSTEM
 (TPMS)
·TURN-SIGNAL LIGHT AND HAZARD
 WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

<VEHICLES WITH KOS>

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-184

CENTRAL DOOR LOCKING SYSTEM (CONTINUED)

DRIVER'S
DOOR
UNLOCK
RELAY

ETACS-ECU

FRONT
POWER
WINDOW
SUB
SWITCH

POWER
WINDOW
MAIN
SWITCH

DOOR
LOCK
SWITCH

DOOR
LOCK
SWITCH

NOTE

: VEHICLES WITH KOS
