Mitsubishi Outlander (2013+). Manual - part 790

CRUISE CONTROL SYSTEM

CIRCUIT DIAGRAMS

90-120

CRUISE CONTROL SYSTEM

M1901032902125

4

FUSIBLE
LINK

2

FUSIBLE
LINK

IG1
RELAY

RELAY BOX

ENGINE
COMPARTMENT

ENGINE
CONTROL
RELAY

THROTTLE
VALVE
CONTROL
SERVO
RELAY

ENGINE-
ECU

ETACS-ECU

STOP LAMP
SWITCH

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver

IGNITION SWITCH (IG1)
OR OSS-ECU (IG1)

RELAY BOX
(PASSENGER
COMPARTMENT)
FUSIBLE LINK
AND FUSE

STOP LAMP
CONTROL CIRCUIT

·OSS-ECU
·SPARE
 CONNECTOR
 (FOR SWITCH
 BOX)

NOTE

: VEHICLES WITHOUT KOS
:
:

VEHICLES WITH KOS

·ABS-ECU
·ASC-ECU
·COLUMN SWITCH
·CORNER SENSOR/
 BACK SENSOR-ECU
·CVT CONTROL RELAY
·EPS-ECU
·HAZARD INDICATOR
 ASSEMBLY
·HEATED SEAT RELAY
·HEATER CONTROLLER
 ASSEMBLY (A/C-ECU)
·KOS-ECU
·SELECTOR LEVER
 ASSEMBLY
·SONAR SWITCH
·STEERING WHEEL
 SENSOR
·SUNROOF MOTOR
 ASSEMBLY

CRUISE CONTROL SYSTEM

CIRCUIT DIAGRAMS

90-121

CRUISE CONTROL SYSTEM (CONTINUED)

CLOCK
SPRING

ENGINE-
ECU

STEERING WHEEL
SPEED CONTROL
SWITCH

HALL IC

ACCELERATOR PEDAL POSITION SENSOR

THROTTLE
VALVE
CONTROL
SERVO

HALL IC

(SUB)

HALL IC

(MAIN)

HALL IC

(SUB)

(MAIN)

ELECTRONIC-
CONTROLLED
THROTTLE
VALVE

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver

THROTTLE POSITION
SENSOR

STEERING
WHEEL
MULTI-FUNCTION
SWITCH

COMBINATION
METER

ENGINE-
ECU

CRUISE CONTROL SYSTEM (CONTINUED)

CAN DRIVE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

DIAGNOSIS
CONNECTOR

(FUSE     )

11

ETACS-ECU

FRONT SIDE

ENGINE-
ECU

INPUT SIGNAL

·COLUMN SWITCH
 (LIGHTING SWITCH)
·LIGHTING CONTROL SENSOR
 <VEHICLES WITH AUTO LAMP
 AND RAIN SENSITIVE AUTO
 WIPER>

INPUT SIGNAL

·INHIBITOR SWITCH (N)
·SECONDARY PULLEY
 SPEED SENSOR

CVT-ECU

NOTE

:
:

VEHICLES WITHOUT ASC
VEHICLES WITH ASC

ABS-ECU

ASC-ECU

ETACS-ECU

CRUISE CONTROL SYSTEM

CIRCUIT DIAGRAMS

90-122

CRUISE CONTROL SYSTEM (CONTINUED)

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver

RHEOSTAT

CPU

CAN TRANSCEIVER
CIRCUIT

(FUSE     )

15

HIGH SIDE
DRIVE CIRCUIT

LED DRIVE
CIRCUIT

COMBINATION
METER

(FUSE     )

19

ETACS-ECU

ETACS-ECU

LCD (CRUISE)

NOTE

: VEHICLES WITHOUT

COLOUR LIQUID CRYSTAL
DISPLAY

ABS <VEHICLES WITHOUT ASC>

CIRCUIT DIAGRAMS

90-123

ABS <VEHICLES WITHOUT ASC>

M1901019201832

CAN
TRANSCEIVER
CIRCUIT

CPU

LED DRIVE
CIRCUIT

LCD

·ABS
·BRAKE

RHEOSTAT

COMBINATION METER

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver

FUSIBLE
LINK

4

ETACS-ECU

STOP LAMP
CONTROL CIRCUIT

STOP LAMP
SWITCH

ABS-ECU

IG1
RELAY

FUSIBLE
LINK

2

IGNITION SWITCH (IG1)
OR OSS-ECU (IG1)

RELAY BOX
(PASSENGER
COMPARTMENT)
FUSIBLE LINK
AND FUSE

·OSS-ECU
·SPARE CONNECTOR
 (FOR SWITCH BOX)

RELAY BOX

ENGINE
COMPARTMENT

·COLUMN SWITCH
·CORNER SENSOR/
 BACK SENSOR-ECU
·CVT CONTROL RELAY
·EPS-ECU
·HAZARD INDICATOR
 ASSEMBLY
·HEATED SEAT RELAY
·HEATER CONTROLLER
 ASSEMBLY (A/C-ECU)
·KOS-ECU
·SELECTOR LEVER
 ASSEMBLY
·SONAR SWITCH
·STEERING WHEEL
 SENSOR
·SUNROOF MOTOR
 ASSEMBLY

NOTE

: VEHICLES WITHOUT KOS
: VEHICLES WITH KOS
