Mitsubishi Outlander (2013+). Manual - part 752

ACB04411

B

AB

Blower relay

Heated seat relay

ETACS-ECU

ECU

COMPONENT LOCATIONS

70-3

ECU

M1701000501972

Name

Symbol

Name

Symbol

4WD-ECU

C

ETACS-ECU

J

ABS-ECU

A

Hands free-ECU

N

ASC-ECU

A

Hazard indicator assembly
(incorporating CPU)

G

CAN box unit <Vehicles with MMCS>

H

Headlamp control unit <Vehicles with
discharge type headlamp>

Q

Column switch (incorporating
column-ECU)

D

Heater controller assembly (A/C-ECU)

G

Combination meter (incorporating CPU) E

KOS-ECU

I

Corner sensor/back sensor-ECU
<Vehicles with reversing sensor
system>

L

OSS-ECU

I

CVT-ECU

C

Power window main switch
(incorporating CPU)

R

Electric tailgate unit assembly
(incorporating electric tailgate control
unit)

P

Receiver antenna module <Vehicles
without KOS>

I

Electrical steering lock <Vehicles with
KOS>

F

SRS-ECU

M

Engine-ECU

B

Sunroof motor assembly (incorporating
CPU)

O

EPS-ECU

K

USB box

N

ACB04465AC

A

B

D

E

F

G

H

I

J

K

L

M

N

C

ACB04714AB

O

P

Q

R

*

ECU

COMPONENT LOCATIONS

70-4

NOTE: *:also equipped at right side.

ACB04417AB

A

ABS-ECU or
ASC-ECU

ACB04416AB

B

Engine-ECU

Relay box

ACB04446AB

C

CVT-ECU

ETACS-ECU

4WD-ECU

ACB04695AB

Column switch
(incorporating
 column-ECU)

D

ACB04440AB

E

Combination meter
(incorporating CPU)

ACB04420AB

F

<Vehicles with KOS>

Electronic
steering lock

ACB04421AB

G

Hazard indicator
assembly
(incorporating CPU)

Heater controller
assembly (A/C-ECU)

ACB04422AB

H

<Vehicles with MMCS>

CAN box unit

ACB04696AB

Receiver antenna module
<Vehicles without KOS>
or KOS-ECU

I

OSS-ECU
<Vehicles with KOS>

ACB04414AB

J

ETACS-ECU

ACB04444AB

K

EPS-ECU

ECU

COMPONENT LOCATIONS

70-5

ACB04697AB

L

<Vehicles with reversing sensor
system>

Corner sensor/
back sensor-ECU

ACB04450AB

M

SRS-ECU

Accelerator
pedal

ACB04423AB

N

Hands free-ECU
or USB box

AC506943

O

AS

Inside
rear view
mirror

Sunroof motor assembly
(incorporating CPU)

ACB04437AB

P

Electric tailgate
unit assembly
(incorporating
electric tailgate
control unit)

ACB04699AB

Q

Headlamp
control unit

Headlamp
assembly

<Vehicles with discharge type
headlamp>

ACB04441AB

R

Power window main switch
(incorporating CPU)

SENSOR

COMPONENT LOCATIONS

70-6

SENSOR

M1701000603265

Name

Symbol

Name

Symbol

A/C pressure sensor

A

Interior temperature sensor

O

Accelerator pedal position sensor

P

Lighting control sensor <Vehicles with
auto lamp and rain sensitive AUTO
wiper>

R

Air flow sensor

F
