Door inside handle removal

1.

Door inside handle
Door outside handle removal
steps

2.

Plug

3.

Door outside handle cover

4.

Door outside handle

5.

Door outside handle gasket

6.

Door outside handle base
Door latch assembly removal
steps

1.

Door inside handle

7.

Screw

<<A>>

8.

Door lock cover

<<A>>

9.

Door latch assembly

>>B<<

10. Door inside lock cable

>>B<<

11. Door inside handle cable
12. Door outside handle rod

Door check removal steps

•

Rear door speaker (Refer to
GROUP 54A, Speaker .)

>>A<<

13. Door check

DOOR

BODY

42A-60

REMOVAL SERVICE POINT

<<A>> DOOR LOCK COVER/ DOOR
LATCH ASSEMBLY REMOVAL

AC904767AB

(3)

(2)

(1)

Door latch assembly

Door lock
cover

Cable

Remove the door lock cover in the following proce-
dures:
1. Release the upper and lower claws of the door

lock cover by using a flat-tipped screwdriver.

2. Pull the cover out a little.

3. With the cover pulled out state, slide it toward

cabled side and remove it from the door latch
assembly.

INSTALLATION SERVICE POINTS

>>A<< DOOR CHECK INSTALLATION

AC904792AB

Identification mark

Install the door check with the following identification
mark facing upward.

Application

Identification
mark

Front door

Left door

FL

Right door

FR

Rear door

Left door

RL

Right door

RR

>>B<< DOOR INSIDE LOCK CABLE/
DOOR INSIDE HANDLE CABLE
INSTALLATION

AC904914AB

Yellow

Door inside handle
lock knob

Door inside
handle knob

Door inside
handle cable

Door inside
lock cable

Blue

DOOR

BODY

42A-61

Connect the door inside lock cable and door inside
handle cable to the door inside handle according to
the identification colour marked on the cables as
shown in the illustration.

INSPECTION

M1421007600990

DOOR LOCK ACTUATOR CHECK

For the inspection of the door lock actuator, refer to
Door Latch Assembly Inspection (

P.42A-47

).

LOCK/UNLOCK SWITCH CHECK <VEHI-
CLES WITH KOS>

AC506541AD

Lock/unlock switch

Door outside
handle base

Switch
position

Terminal
number

Normal value

ON

1

− 2

Continuity
exists (2

Ω or

less)

OFF

1

− 2

No continuity

CENTRAL DOOR LOCK SWITCH CHECK

Remove the power window switch (Refer to GROUP
52A

− Door Trim ).

ACC00124

AC

Switch
position

Tester connection

Specified
condition

LOCK

8

− 22

Continuity exists
(2

Ω or less)

OFF

8

− 22, 8 − 23

Open circuit

UNLOCK

8

− 23

Continuity exists
(2

Ω or less)

Switch
position

Terminal
number

Normal value

DOOR

BODY

42A-62

WINDOW GLASS RUNCHANNEL AND
DOOR OPENING WEATHERSTRIP

REMOVAL AND INSTALLATION

M1423003101914

ACC00292

ACB05626

ACB05814

ACB05815

ACB05782

11

25 ± 4 N·m

1

1

8

2

9

12

3

5

AB

10

7

4

6

5.0 ± 1.0 N·m

(B)

(A)

<Front door>

Sealant: 3M™ ATD Part No. 8625
or equivalent

: Claw positions

Clip (B)

Clip (A)

A

A

A

A

A

A

A

A

A

A

B

B

B

B

Section A – A

Section B – B

Clip

6

Clip

6

ACC00459

ACC00236

ACC00234

ACC00237

Clip

Flat-tipped
screwdriver

Door window
glass assembly

Door beltline moulding

Front

Door beltline
moulding

Section A – A

NOTE
         : Clip positions

AB

B

A

A

B

Section B – B

Door beltline
moulding

Waterproof film removal steps

•

Door trim assembly (Refer to
GROUP 52A

− Door Trim .)

>>

A

<<

1.

Waterproof film
Door window glass runchannel
removal steps

2.

Door window glass runchannel
Door beltline weatherstrip inner
removal steps

•

Door trim assembly (Refer to
GROUP 52A

− Door Trim .)

3.

Door beltline weatherstrip inner
Door speaker cover removal
steps <Vehicles with audio
amplifier>

•

Door trim assembly (Refer to
GROUP 52A

− Door Trim .)

>>

A

<<

1.

Waterproof film

4.

Door speaker cover
Door beltline moulding removal
steps

•

Door mirror assembly (Refer to
GROUP 51

− Door Mirror .)

5.

Door beltline moulding
Door opening weatherstrip lower
removal

6.

Door opening weatherstrip lower

Door speaker bracket removal
steps <Vehicles with audio
amplifier>

•

Door trim assembly (Refer to
GROUP 52A

− Door Trim .)

>>

A

<<

1.

Waterproof film

7.

Door speaker bracket
Front lower sash removal steps

•

Door trim assembly (Refer to
GROUP 52A

− Door Trim .)

>>

A

<<

1.

Waterproof film

7.

Door speaker bracket <Vehicles
with audio amplifier>

8.

Front lower sash

9.

Door window glass runchannel rear
Door opening weatherstrip inner
removal steps

•

Cowl side trim and front scuff plate
(Refer to GROUP 52A

− Interior

Trim .)

10. Door opening weatherstrip inner

Door opening weatherstrip outer
removal steps

11. Door check connecting bolt

<<

A

>>

12. Door opening weatherstrip outer

DOOR

BODY

42A-63
