SYSTEM OPERATION

KEYLESS OPERATION SYSTEM (KOS)

42B-28

Door lock
does not
operate
(keyless
operation
key is
located
inside the
vehicle).

KEY STILL
IN VEHICLE

The lock/unlock
switch of the front
door outside
handle is pressed
when the keyless
operation key is
still located inside
the car.

• Warning

indicator
display for 5
seconds.

• Outer buzzer

sounds for
2.96 seconds
in pattern 1.

• Lock/unlock switch

of the front door
outside handle is
pressed again.

• 5 seconds have

passed after the
warning output
started.

Door lock
does not
operate
(door open).

CHECK
DOORS

The lock/unlock
switch on the front
door outside
handle is pressed
when the door is
ajar.

• Warning

indicator
display for 5
seconds.

• Outer buzzer

sounds for
2.96 seconds
in pattern 1.

• All doors are

closed.

• 5 seconds have

passed after the
warning output
started.

System
error

KEYLESS
OPERATIO
N SYSTEM
SERVICE
REQUIRED

Engine switch is
pressed when an
error has been
detected in
EEPROM of
KOS-ECU.

The warning
indicator display
for 5 minutes.

5 minutes have
passed after the
engine switch is
pressed, also the
power supply mode is
OFF.

Engine switch is
pressed when a
transmission
antenna has an
open circuit or
short to power
supply.

Open circuit or
short to earth is
detected in the key
slot.

An error is
detected, and the
power supply
mode is other than
OFF.

No keyless
operation
key detected
inside the
car

KEY NOT
DETECTED
INSERT
KEY INTO
KEY SLOT

No keyless
operation key is
detected inside the
car when the
engine switch is
pressed.

The warning
indicator display
for 5 seconds.

• Power supply mode

OFF is detected.

• 5 seconds have

passed after the
warning output
started.

Item

Display content

State

Warning
operation

Warning cancellation
condition (when any
of the condition met)

AC809615

AC809615

AC809615

AC904250

Downloaded from

www.Manualslib.com



manuals search engine



SYSTEM OPERATION

KEYLESS OPERATION SYSTEM (KOS)

42B-29

OSS WARNING AND WARNING INDICATOR LIST

When OSS failed or operated improperly, KOS-ECU
warns the driver to that effect by displaying the
one-touch start system warning on the multi informa-
tion display in the combination meter.

Key
reminder

REMOVE
KEY FROM
KEY SLOT

With the driver's
door kept open,
the keyless
operation key is
not removed from
the key slot.

• The warning

indicator
display for 1
minute.

• Outer buzzer

sounds for
2.96 seconds
in pattern 1.

• Key is removed

from the key slot.

• 1 minutes have

passed after the
warning output
started.

Engine
switch
reminder

−

The lock/unlock
switch on the front
door outside
handle (driver's
side, front
passenger's side)
or the tailgate lock
release handle
(tailgate open
switch, tailgate
lock switch) are
pressed when the
power supply
mode is other than
OFF.

• Warning

indicator
display for 5
seconds.

• Outer buzzer

sounds for
2.96 seconds
in pattern 1.

5 minutes have
passed after the
engine switch is
pressed, also the
power supply mode is
OFF.

Item

Display content

State

Warning
operation

Warning cancellation
condition (when any
of the condition met)

AC904251

AC904252

AC501053AC

T

1

T

2

T

1

: 0.08 ± 0.01 seconds

T

1

T

2

: 2.96 seconds

T

3

T

3

T

3

T

3

T

4

T

4

T

4

T

5

T

5

T

5

T

5

T

6

T

6

T

6

T

3

: 1.01 seconds

T

4

: 0.55 seconds

T

5

: 0.17 ± 0.01 seconds

T

6

: 0.11 ± 0.01 seconds

T

7

: 5.69 seconds

<Sound pattern 1>

<Sound pattern 2>

T

7

Downloaded from

www.Manualslib.com



manuals search engine



SYSTEM OPERATION

KEYLESS OPERATION SYSTEM (KOS)

42B-30

Item

Display contents

Factor

Immobilizer error

IMMOBILIZER SYSTEM
SERVICE REQUIRED

• Displayed when the

certification communication
fails with KOS, electrical
steering lock, or
engine-ECU.

• Displayed when the power

supply mode is turned ON
while the keyless operation
key is judged to be brought
outside the vehicle with the
power supply mode in ACC,
or when the engine starting
operation is performed after
such a status.

• Displayed when the

electrical steering lock
cannot be locked because
there is a P detection switch
malfunction.

Steering turn
indication

PUSH ENGINE SWITCH
WHILE TURNING
STEERING WHEEL

Displayed when the steering
lock is not unlocked because
the steering force is applied.

Electrical steering
lock malfunction

STEERING LOCK
SERVICE REQUIRED

Displayed when a malfunction
occurs to the steering lock
system.

Shift P indication

SHIFT TO P POSITION

Displayed if the shift lever is in
other than "P" range when the
engine is not running.

Steering lock not
locked

STEERING WHEEL
UNLOCKED

Displayed when the door is
open with the steering lock not
locked.

Power supply
system error

ELECTRICAL SYSTEM
SERVICE REQUIRED

Displayed when an error occurs
to the power supply system.

AC904253

AC904254

AC904255

AC904256

AC904257

AC904260

Downloaded from

www.Manualslib.com



manuals search engine



CUSTOMISATION FUNCTION

KEYLESS OPERATION SYSTEM (KOS)

42B-31

CUSTOMISATION FUNCTION

M2421000300559

By operating the M.U.T.-III ETACS system, the fol-
lowing functions can be customised. The pro-
grammed information is held even when the battery
is disconnected.

Engine starting
method

PRESS BRAKE PEDAL
TO START ENGINE

Displayed when the shift lever
is in other than "P" range or "N"
range at the engine start, or
when the engine switch is
pressed without the brake
pedal depressed.

Power OFF
indication

−

Displayed when the door is
open with the power supply
mode in ON or in ACC.

Item

Display contents

Factor

AC904258

AC904252

Adjustment
item (M.U.T.-III
display)

Adjustment item

Adjusting content
(M.U.T.-III display)

Adjusting content

Hazard answer
back

Adjustment of the
number of keyless
hazard warning
lamp answer back
flashes

Lock:1, Unlock:2

LOCK: Flashes once, UNLOCK: Flashes
twice (initial condition)

Lock:1, Unlock:0

LOCK: Flashes once, UNLOCK: No flash

Lock:0, Unlock:2

LOCK: No flash, UNLOCK: Flash twice

Lock:2, Unlock:1

LOCK: Flash twice, UNLOCK: Flash once

Lock:2, Unlock:0

LOCK: Flash twice, UNLOCK: No flash

Lock:0, Unlock:1

LOCK: No flash, UNLOCK: Flash once

Lock:0, Unlock:0

No function

Auto fold mirror

Electric folding door
mirror automatic
unfolding function
<vehicles with
electric retractable
remote controlled
door mirrors>

Not Auto

No synchronised operation

Open Vehicle SPD

Vehicle speed-dependent operation

Open/Close by IG

Ignition switch linked operation

OPN/CLS Keyless

Keyless entry linked operation (initial
condition)

Auto door
unlock

Adjustment of the
auto door unlock
function

Disable

Without function <M/T, A/T, CVT> (initial
condition)

Always (P pos)

With function: Operates when the shift
lever or the selector lever is moved to the
P position. <A/T, CVT>

Always(Lock pos)

With function: Operates when the ignition
switch is moved to the LOCK (OFF)
position. <M/T, A/T, CVT>
