MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS
TSB Revision
MULTIPORT FUEL INJECTION (MFI)
13A-617
STEP 14. Using scan tool MB991958, check evaporative
emission system monitor test.
CAUTION
• To prevent damage to scan tool MB991958, always turn
the ignition switch to the "LOCK" (OFF) position before
connecting or disconnecting scan tool MB991958.
• During this test, the PCM automatically increases the
engine speed to 1,600 r/min or greater. Check that the
transmission is set to "P" position.
(1) Connect scan tool MB991958 to the data link connector.
(2) Turn the ignition switch to the "ON" position.
(3) Erase the DTCs using scan tool MB991958.
(4) Check that the fuel cap is securely closed. (Tighten until
three clicks are heard).
(5) Start the engine.
(6) Select "System Test" and press the "YES" key.
(7) Select "Evap Leak Mon" and press the "YES" key.
(8) During this test, keep the accelerator pedal at the idling
position.
NOTE: If the engine speed does not reach 2,000 r/min dur-
ing the monitor test, adjust the Speed Adjusting Screw
(Refer to
), and adjust to the standard value.
(9) Keep the engine speed and engine load within the specified
range. When the monitor test starts, the "In Progress" item
on scan tool MB991958 will change from "NO" to "YES".
(10)Turn the ignition switch to the "LOCK" (OFF) position.
Q: Is "Evap Leak Mon. Completed. Test Failed and DTCs
Set" displayed on scan tool MB991958?
YES : Replace the PCM. Then go to Step 19 .
NO <"Evap Leak Mon. Completed. Test Passed" is
displayed on scan tool MB991958.> : The evaporative
emission system is working properly at this time. Then
go to Step 19 .
NO <"Evap Leak Mon. Discontinued. Retest again from
the first" is displayed on scan tool MB991958.> : The
EVAP monitor has been interrupted during the test.
Turn the ignition switch to the "LOCK" (OFF) position
once, and repeat the monitor test.
AK303629AB
MB991911
MB991827
MB991824
16-PIN
