TREATMENT BEFORE/AFTER DRIVING THROUGH WATER

TSB Revision

GENERAL <BODY AND CHASSIS>

00-27

• Apply grease to the lubricating points of the front

suspension, steering linkage and propeller shaft.

AC003353AB

PITMAN ARM

TIE ROD

UPPER ARM

TIE ROD END

TREATMENT BEFORE/AFTER DRIVING THROUGH WATER

TSB Revision

GENERAL <BODY AND CHASSIS>

00-28

INSPECTION AND SERVICE AFTER
FORDING A STREAM

After fording a stream, check the following points. If
abnormal condition is evident, clean, replace or lubri-
cate.

• Check for water, mud, sand, etc. in the rear brake

drum, starter motor, brake pipe and fuel pipe.

• Check for water in the fluid or oil inside the front

differential, rear differential, transmission and
transfer.

• Apply grease to the lubricating points of the front

suspension, steering linkage and propeller shaft.

• Check all boots and breather hoses for cracks

and damage.

AC003354

TOWING AND HOISTING

TSB Revision

GENERAL <BODY AND CHASSIS>

00-29

TOWING AND HOISTING

M1001000800250

WRECKER TOWING RECOMMENDATION

.

FRONT TOWING PICKUP

CAUTION

• Do not tow this vehicle with a wrecker using sling-type

equipment other wise the bumper may become
deformed. If this vehicle is towed, use wheel lift or flat
bed equipment.

• Make sure that the transmission remains in the "N"

position.

• For the four-wheel-drive vehicle, move the transfer shift

lever to "2H" position.

The vehicle may be towed on its rear wheels for extended dis-
tances provided the parking brake is released. It is recom-
mended that vehicles be towed using the front pickup
whenever possible.

.

REAR TOWING PICKUP

CAUTION

• This vehicle cannot be towed by a wrecker using

sling-type equipment other wise the lower arm may
become deformed. If this vehicle is towed, use a wheel
lift or flat bed equipment.

• Do not use the steering column lock to secure the front

wheels for towing.

• For the four-wheel-drive vehicle, move the transfer shift

lever to "2H" position.

• If these requirements cannot be met, the front wheels

must be placed on a tow dolly.

Automatic transmission vehicle may be towed on the front
wheels at speeds not to exceed 50 km/h (30 mph) for distances
not to exceed 30 km (18 miles).

.

ACX00883 AB

SLING TYPE

WHEEL LIFT TYPE

FLAT BED TYPE

NO

ACX00884 AB

SLING TYPE

WHEEL LIFT TYPE

FLAT BED TYPE

NO

TOWING AND HOISTING

TSB Revision

GENERAL <BODY AND CHASSIS>

00-30

TOWING WHEN KEYS ARE NOT AVAILABLE
When a locked vehicle must be towed and keys are not avail-
able, the vehicle may be lifted and towed from the front, pro-
vided the parking brake is released. If not released, the rear
wheels should be placed on a tow dolly.

HOISTING

.

EMERGENCY JACKING
Place a jack under one of the jacking points shown in the illus-
tration.

.

AC003355

FRONT JACK-UP
POINT

REAR JACK-UP
POINT

AB
