DOOR

TSB Revision

BODY

42-43

INSPECTION

M1421007600525

FRONT DOOR LOCK ACTUATOR CHECK

Actuator Operation Check <Driver’s side>

Actuator Operation Check <Passenger’s side>

Actuator Switch Check <Driver’s side>

Actuator Switch Check <Passenger’s side>

LEVER
POSITION

BATTERY CONNECTION

LEVER
OPERATION

At the
"LOCK"
position

• Connect terminal 6 to the

negative battery terminal

• Connect terminal 4 to the

positive battery terminal

The lever moves
from the "LOCK"
position to the
"UNLOCK" position.

At the
"UNLOCK"
position

• Connect terminal 4 to the

negative battery terminal

• Connect terminal 6 to the

positive battery terminal

The lever moves
from the "UNLOCK"
position to the
"LOCK" position.

LEVER
POSITION

BATTERY CONNECTION

LEVER
OPERATION

At the
"LOCK"
position

• Connect terminal 4 to the

negative battery terminal

• Connect terminal 6 to the

positive battery terminal

The lever moves
from the "LOCK"
position to the
"UNLOCK" position.

At the
"UNLOCK"
position

• Connect terminal 6 to the

negative battery terminal

• Connect terminal 4 to the

positive battery terminal

The lever moves
from the "UNLOCK"
position to the
"LOCK" position.

SWITCH
POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

LOCK

1

− 3

Less than 2 ohms

UNLOCK

1

− 2

SWITCH
POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

LOCK

2

− 3

Open circuit

UNLOCK

2

− 3

Less than 2 ohms

AC000039

LOCK

UNLOCK

VIEW A

VIEW B

UNLOCK

LOCK

B

<DRIVER'S SIDE>

<PASSENGER'S SIDE>

AF

A

LEVER

LEVER

DOOR

TSB Revision

BODY

42-44

REAR DOOR LOCK ACTUATOR CHECK

Actuator Operation Check <Driver’s side>

Actuator Operation Check <Passenger’s side>

DOOR LOCK KEY CYLINDER SWITCH CHECK

 <Driver’s side>

 <Passenger’s side>

LEVER
POSITION

BATTERY CONNECTION

LEVER
OPERATION

At the
"LOCK"
position

• Connect terminal 3 to the

negative battery terminal

• Connect terminal 2 to the

positive battery terminal

The lever moves
from the "LOCK"
position to the
"UNLOCK" position.

At the
"UNLOCK"
position

• Connect terminal 2 to the

negative battery terminal

• Connect terminal 3 to the

positive battery terminal

The lever moves
from the "UNLOCK"
position to the
"LOCK" position.

LEVER
POSITION

BATTERY CONNECTION

LEVER
OPERATION

At the
"LOCK"
position

• Connect terminal 2 to the

negative battery terminal

• Connect terminal 3 to the

positive battery terminal

The lever moves
from the "LOCK"
position to the
"UNLOCK" position.

At the
"UNLOCK"
position

• Connect terminal 3 to the

negative battery terminal

• Connect terminal 2 to the

positive battery terminal

The lever moves
from the "UNLOCK"
position to the
"LOCK" position.

ACX02355

ACXO2356

ACX00545

A

B

LOCK

UNLOCK

VIEW A

VIEW B

UNLOCK

LOCK

<DRIVER'S SIDE>

<PASSENGER'S SIDE>

AE

LEVER

LEVER

SWITCH
POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

LOCK

2

− 3

Less than 2 ohms

NEUTRAL (OFF)

1

− 2, 1 − 3, 2 − 3

Open circuit

UNLOCK

1

− 2

Less than 2 ohms

SWITCH
POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

LOCK

1

− 2

Less than 2 ohms

NEUTRAL (OFF)

1

− 2, 1 − 3, 2 − 3

Open circuit

UNLOCK

2

− 3

Less than 2 ohms

ACX02410

1

2

3

DOOR

TSB Revision

BODY

42-45

CENTER DOOR LOCK SWITCH CONTINUITY
CHECK

Remove the power window switch. (Refer to

P.42-31

.)

<Driver’s side>

<Passenger’s side>

SWITCH
POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

LOCK

3

− 12

Less than 2 ohms

OFF

3

− 10, 3 − 12, 10 − 12 Open circuit

UNLOCK

3

− 10

Less than 2 ohms

SWITCH
POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

LOCK

1

− 2

Less than 2 ohms

OFF

1

− 2, 1 − 3, 2 − 3

Open circuit

UNLOCK

2

− 3

Less than 2 ohms

7

6

5

4

3

2

1

14

13

12

11

10

9

8

ACX02412

5

4

3

2

1

10

9

8

7

6

ACX02413

AC000122

<DRIVER'S SIDE>

<PASSENGER'S SIDE>

AB

DOOR

TSB Revision

BODY

42-46

WINDOW GLASS RUNCHANNEL AND DOOR OPENING WEATHERSTRIP

REMOVAL AND INSTALLATION

M1423003100353

AC203989

:SECTIONAL VIEW OF
 CLIP POSITION

:SECTIONAL VIEW OF
 CLIP POSITION

CLIP

2

CLIP

2

1

2

3

4

5

AC

<FRONT DOOR>

DOOR INNER OPENING
WEATHERSTRIP REMOVAL STEPS

>>B<<

1. DOOR INNER OPENING

WEATHERSTRIP

• SCUFF PLATE, CENTER PILLAR

LOWER TRIM AND COWL SIDE
TRIM (REFER TO GROUP 52A,
TRIMS

P.52A-8

.)

DOOR OUTER OPENING
WEATHERSTRIP REMOVAL
• FRONT DOOR CHECK MOUNTING

BOLT (DOOR SIDE) (REFER TO

P.42-29

.)

<<A>>

2. DOOR OUTER OPENING

WEATHERSTRIP

DOOR WINDOW GLASS
RUNCHANNEL REMOVAL STEPS
3. DOOR WINDOW GLASS

RUNCHANNEL

• FRONT DOOR TRIM (REFER TO

P.42-31

.)

>>A<<

4. DOOR BELTLINE INNER

WEATHERSTRIP

DOOR BELTLINE MOLDING REMOVAL
STEPS
5. DOOR BELTLINE MOLDING
