SPECIAL TOOLS
TSB Revision
AUTOMATIC TRANSMISSION OVERHAUL
23B-7
MD998304
Oil seal installer
MD998304-01
Measurement of output
shaft end play
MB991632
Clearance dummy plate
−
Measurement of brake
reaction plate, second
brake and low/reverse
brake end plays
MD998913
Dial gauge extension
MD998913-01
Measurement of brake
reaction plate, second
brake and low/reverse
brake end plays
MD998412
Guide
MD998412
Installation of oil pump
MD998316
Dial gauge support
MIT209038
Measurement of input
shaft end play
MD998924
Spring compressor
retainer
−
Use with spring
compressor
MD999590
Spring compressor
−
Removal and installation
of reverse and overdrive
clutch spring retainer
snap ring
MB991629
Spring compressor
−
Measurement of
overdrive clutch and
underdrive clutch end
plays
TOOL
TOOL NUMBER AND
NAME
SUPERSESSION
APPLICATION
