DIAGNOSIS TSB Revision CONTROLLER AREA NETWORK (CAN) 54C-451 . TROUBLE JUDGMENT ± 20 Ω. . COMMENTS ON TROUBLE SYMPTOM . TROUBLESHOOTING HINTS • The wiring harness or connectors may have loose, corroded, or damage terminals, or termi- • The combination meter may be defective • The ABS-ECU may be defective • The powertrain control module may be defective DIAGNOSIS Required Special Tools: • MB991223: Harness Set • MB991970: ABS Check Harness AC305206 CONNECTOR: A-02 AR A-02 (GR) AC306248AB B-19 (B) CONNECTOR: B-19 AIR PCM AC305231CA C-101 C-29 C-02 CONNECTORS: C-02, C-29, C-101 |
