CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-143

RELAY
BOX

BATTERY

HORN
RELAY

ETACS-
ECU

HORN

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW
SB : SKY BLUE     BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET

HORN

JUNCTION BLOCK SIDE

CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-144

CENTRAL DOOR LOCKING SYSTEM (CONTINUED)

BATTERY

RELAY
BOX

ETACS-
ECU

FRONT
COMBINATION
LIGHT (RH)

FRONT
COMBINATION
LIGHT (LH)

JUNCTION
BLOCK SIDE

TURN-SIGNAL
LIGHT RELAY
: LH

TURN-SIGNAL
LIGHT RELAY
: RH

CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-145

RECEIVER

REAR
COMBINATION
LIGHT
(RH)

REAR
COMBINATION
LIGHT (LH)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW
SB : SKY BLUE     BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET

JUNCTION
BLOCK

CONTROL CIRCUIT

TRANSMITTER

CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-146

CENTRAL DOOR LOCKING SYSTEM (CONTINUED)

IGNITION
SWITCH (ACC)

WINDSHIELD WIPER
AND WASHER

ETACS-
ECU

JUNCTION
BLOCK

·AUDIO SYSTEM
·AUTOMATIC AIR
 CONDITIONING SYSTEM
·CONTROLLER
 AREA NETWORK(CAN)
·MANUAL AIR
 CONDITIONING SYSTEM
·MULTI CENTER
 DISPLAY

RELAY
BOX
